JBL AM5212/64 Medium Power 12" 2-Way Full-Range Loudspeaker

JBL AM5212/64 Medium Power 12" 2-Way Full-Range Loudspeaker

SoundPro Item: 46627 | Part Number: AM5212/64

$2,500.00
$2,500.00 $2,500.00
Your Price Sold out
MSRP: $2,500.00 | MAP: $2,500.00

Usually ships in 5-7 business days

  • Rotatable Progressive Transition Waveguide Optimizes Coverage For Vertical Or Horizontal Mounting
  • Differential Drive Dual Voice Coil Low-Frequency Driver Reduces Harmonic Distortion
  • 60° x 40° Consistent Coverage Pattern Minimizes Hot Spots And Dead Zones
  • Bi-Amp And Passive Switchable Modes Enable Flexible Integration With Any Amplifier Chain
  • FIR-Tuned Frequency And Phase Response Maintains Tonal Accuracy In Both Operating Modes
  • Available In Black, White, And Weather-Resistant Finishes For Diverse Venue Requirements
Log in or register for YOUR best price

The JBL AM5212/64 is a medium-power portable PA speaker engineered for sound engineers and system integrators who require predictable coverage and reliable performance in live sound and touring applications. The 262H Differential Drive low-frequency driver and 2408H-1 compression driver deliver clear, full-range reproduction from 37 Hz to 20 kHz, making it suitable for speech, music, and event reinforcement across club, theater, and portable stage environments.

The 60° x 40° rotatable Progressive Transition waveguide offers excellent pattern control and distortion rejection while allowing vertical or horizontal orientation to match room geometry or rigging requirements. Bi-amp and passive switchable crossover modes with FIR tuning optimize frequency response and phase consistency in either configuration, giving you flexibility to integrate with powered processors or passive amplifier chains without compromising sound quality.

Available in black, white, and weather-resistant finishes, the AM5212/64 includes pole cups and suspension eyebolt provisions for flexible deployment in temporary or permanent installations. Optional MTU-3 brackets provide additional rigging options for touring rigs and rental fleets.

Downloads

View full details

Specifications

Frequency
Frequency Range (-10 dB)|37 Hz – 20 kHz
Frequency Response (±3 dB)|43 Hz – 18 kHz
Crossover Frequency (Passive)|1.5 kHz
Coverage
Coverage Pattern|60° x 40°
Transducers
Low-Frequency Driver|262H-1 Differential Drive, 12"
High-Frequency Driver|2408H-1 Compression Driver, 38 mm (1.5") Exit
Power Rating (AES)
Low-Frequency (2 hours)|400 W, 1600 W peak
Low-Frequency (100 hours)|300 W, 1200 W peak
High-Frequency (2 hours)|40 W, 160 W peak
Crossover
Modes|Bi-Amp/Passive Switchable
Tuning|FIR (Finite Impulse Response) optimized for frequency, phase response, and coverage consistency
