JBL Control 442C/T-U Compact Ceiling Speaker | White

JBL Control 442C/T-U Compact Ceiling Speaker | White

SoundPro Item: 202165 | Part Number: JBL-C442C/T-U

$175.00
$175.00 $175.00
Your Price Sold out
MSRP: $175.00 | MAP: $175.00

Usually ships in 5-7 business days

  • 70V/100V taps plus 16Ω input for system flexibility
  • Integrated enclosure suits plenum ceiling spaces
  • Top or side cable entry eases wiring access
  • Captive dogears fit varied ceiling thicknesses
  • Paintable magnetic grille blends with interiors
  • IP33 rating supports indoor environmental use
Log in or register for YOUR best price

The Control 442C/T is a compact in-ceiling loudspeaker built for installed audio applications where space above the ceiling is limited. Its integrated enclosure suits most ceiling plenum spaces, and the design supports both distributed and low-impedance system configuration.

Mounting and wiring are streamlined with top or side cable entry, captive hand-screws on the terminal cover, and captive dogears that adapt to varied ceiling thicknesses. A full-face magnetic grille is included and can be painted to match the room finish.

View full details

Specifications

Performance
Frequency Range (-10 dB)
130Hz - 20kHz
Power Capacity
22.5 W (90 W Peak), Cont. Pink Noise (2 hrs.) 15 W (60 W Peak) Cont. Pink Noise Power (100 hrs.)
Sensitivity (1m/1W)
86dB
Coverage Angle
160° conical
Maximum SPL (1m)
99.5 dB Cont. pink noise (105.5 dB peak)
Nominal Impedance
16Ω
Transformer Taps
70 V: 12 W, 6 W & 3 W 100 V: 12 W, 6 W
Driver
Drivers
60 mm (2.5 in) Full Range driver with paper cone, Rubber surround, CCAW coil
Installation
Ceiling Cutout Size
104 mm (4.1 in)
Dimensions
138 mm (5.4 in) H x 131 mm (5.2 in) dia. 129 mm (5.1 in) from bottom of ceiling tile to top of backcan
Compliance and Environmental
Safety Agency Rating
Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.
Environmental
IP rating: IP33 per EN/IEC 60529. Operating temperature: 0° C to 45 °C.
Accessories and Finish
Optional Accessories
JBL-MTC-442BG black (RAL9004) round grille JBL-MTC-442SG white (RAL9003) square grille JBL-MTC-442NC new construction bracket JBL-MTC-442MR mud-ring construction bracket JBL-MTC-48TRX4 tile rail for 4' x 4' ceiling tiles
Color
Stock grille is White (RAL9003), paintable
Weights and Identification
Net Weight (ea)
1.1 kg (2.43 lbs)
Shipping Weight (pair)
3.22 kg (7.1 lbs)
SKU Numbers
JBL-C442C/T
