JBL Control 445C/T 5.25" RBI™-Equipped Two-Way Coaxial Ceiling Loudspeaker

JBL Control 445C/T 5.25" RBI™-Equipped Two-Way Coaxial Ceiling Loudspeaker

SoundPro Item: 202166 | Part Number: JBL-C445C/T

$402.00
$402.00 $402.00
Your Price Sold out
MSRP: $402.00 | MAP: $402.00

In stock and ready to ship

  • 130 mm (5.25 in) woofer and 20 mm (0.75 in) soft-dome tweeter
  • JBL’s exclusive conical Radiation Boundary Integrator® (RBI™) technology
  • Integrated enclosure that is ideal for installation in most ceiling plenum spaces
  • Built-in 70V/100V multi-tap transformer, plus 8-ohm direct input
  • Full-face, easily paintable magnetic grilles
  • Top and side cable entry options
  • Robust and adaptable dogears for wide range of ceiling thicknesses
  • IP33 rated
Log in or register for YOUR best price

The JBL Control 445C/T, part of the flagship Control 400 Premium Coverage Series, is a two-way coaxial ceiling loudspeaker featuring a 5.25” woofer, conical RBI™, and an integrated enclosure that is ideal for installation in most ceiling plenum spaces.

Featuring JBL’s proprietary conical Radiation Boundary Integrator® (RBI™) technology, the Control 445C/T achieves constant directivity coverage, ensuring that listeners can enjoy an especially smooth sound character that remains extremely consistent, clear, and pleasant across a wide coverage area.

Control 400 Series ceiling speakers boast thoughtfully engineered mounting features to enhance safety, efficiency, and repeatability. Terminal covers allow for convenient top or side cable entry and are secured effortlessly with captive hand-screws. The reliable captive dogear design accommodates a variety of ceiling thicknesses, ensuring versatility for any environment.

All models embrace design elements tailored for modern interiors. The included full-face magnetic grille is paintable for seamless integration into any decor, while available black and square grilles provide added customization. Additionally, the Control 445C/T supports both 70V/100V and low impedance applications.

View full details

Specifications

Frequency Range (-10 dB)
55Hz - 20kHz
Power Capacity
112 W (448 W Peak), Cont. Pink Noise (2 hrs.); 75 W (300 W Peak) Cont. Pink Noise Power (100 hrs.)
Sensitivity (1m/1W)
88dB
Coverage Angle
120° conical
Maximum SPL (1m)
108.5 dB Cont. pink noise (114.5 dB peak)
Nominal Impedance
8Ω
Transformer Taps
70 V: 60 W, 30 W, 15 W & 7.5 W; 100 V: 60 W, 30 W, 15 W
Drivers
LF: 130 mm (5.25 in) with treated paper cone and high-performance magnet; HF: 20 mm (0.75 in) soft-dome with Neodymium magnet
Ceiling Cutout Size
223 mm (8.8 in)
Dimensions
255 mm (10.4 in) H x 260 mm (10.2 in) dia.; 240 mm (9.6 in) from bottom of ceiling tile to top of backcan
Safety Agency Rating
Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.
Environmental
IP rating: IP33 per EN/IEC 60529.; Operating temperature: 0° C to 45 °C.
Color
Stock grille is White (RAL9003), paintable
Net Weight (ea)
4.3 kg (9.48 lbs)
Shipping Weight (pair)
13.83 kg (30.49 lbs)
SKU Numbers
JBL-C445C/T
