Specifications
Dimensions
Dimensions (including Mounting flange)
1.75”H x 9”W x 9.5”D
Electrical
Technical Current Rating
12A
Audio
Power Output
Three NEMA 5/15R: two addressable, one unswitched
Connectivity
Power Input
Detachable NEMA 18 AWG power cord with right angle plug
Network Communication
On board web server (GUI), TCP/IP or UDP
Construction
Chassis
16 gauge steel
Controls
LED Indicators
Network, surge protection, external fault (RX model only) and pod status (2)
Shipping
Weight
5 lbs
General
Circuit Breaker (thermal)
15A
Number of Addressable Power Pods
2
Number of Unswitched Outlets
1
Signal Connection
Ethernet (RJ-45)
Power
Input Voltage
120 VAC @ 60Hz
