Kramer C-BM/BM BNC Coax Video Cable | Length: 100 feet

Kramer C-BM/BM BNC Coax Video Cable | Length: 100 feet

SoundPro Item: 97011 | Part Number: C-BM/BM-100

$53.10
$68.00 $53.10
Your Price Sold out
MSRP: $68.00 | MAP: $53.10

Usually ships in 5-7 business days

  • Quality Construction — RG–6 cable for the highest resolution signals
  • High–Quality Connectors — True 75Ω BNC connectors maintain correct impedance end–to–end
  • Varied Selection of Lengths — Available in versions of 1.5 to 150ft (0.5 to 45.7m)
  • Tested to 3G
Log in or register for YOUR best price

Kramer’s C−BM/BM is constructed of high performance RG−6 cable with 75Ω BNC connectors at each end. It offers outstanding quality, durability, and high performance for any video signal application.

View full details
  • COAX
    • Conductor: 18 AWG solid bare copper
    • Dielectric: Skin foam
    • Shield: (A) 61% braid 34 AWG aluminum wire
    • Shield: (B) Dual foil/Mylar 25% overlap rate
  • Construction
    • Outside Jacket: PVC
    • Outside Jacket Color: Dark gray with white lettering
  • Diameters
    • Center Conductor: 1.02mm (0.0403in)
    • Dielectric: 4.57mm (0.179in)
    • Outside Diameter: 6.95mm (0.391in)
  • Electrical
    • Impedance: 75Ω
    • DC Resistance: 21.8Ω/km (6.6Ω/1000ft)
    • Capacitance: 53.1pF/m (16.1pF/ft)
    • Velocity of Propagation: 82%
    • Temperature: –20° to 75°C (–4° to 167°F)
    • Attenuation (dB/100 ft.): –0.3dB @1MHz
    • Attenuation (dB/100 ft.): –0.6dB @5MHz
    • Attenuation (dB/100 ft.): –0.8dB @10MHz
    • Attenuation (dB/100 ft.): –1.6dB @50MHz
    • Attenuation (dB/100 ft.): –2.0dB @100MHz
    • Attenuation (dB/100 ft.): –2.8dB @180MHz
    • Attenuation (dB/100 ft.): –4.4dB @400MHz
    • Attenuation (dB/100 ft.): –5.7dB @750MHz
    • Attenuation (dB/100 ft.): –6.7dB @1000MHz
  • Regulatory
    • UL: CL2
    • CSA: C(UL) CL2
