Specifications
Dimensions
Outside Diameter
6.95mm (0.391in)
Electrical
Dielectric
Skin foam
Audio
Impedance
75Ω
Performance
DC Resistance
21.8Ω/km (6.6Ω/1000ft)
Capacitance
53.1pF/m (16.1pF/ft)
Construction
Conductor
18 AWG solid bare copper
Shield
(A) 61% braid 34 AWG aluminum wire
Outside Jacket Color
Dark gray with white lettering
Environmental
Temperature
–20° to 75°C (–4° to 167°F)
General
Outside Jacket
PVC
Center Conductor
1.02mm (0.0403in)
Velocity of Propagation
82%
Attenuation (dB/100 ft.)
–0.3dB @1MHz
UL
CL2
CSA
C(UL) CL2
