Kramer VW-9 HDMI 2.0 Multiview Video Wall Processor

Kramer VW-9 HDMI 2.0 Multiview Video Wall Processor

SoundPro Item: 207571 | Part Number: VW-9

$8,464.00
$10,580.00 $8,464.00
Your Price Sold out
MSRP: $10,580.00 | MAP: $8,464.00

Usually ships in 5-7 business days

  • Flexible Wall Configuration Supports Any Arrangement Up To Ten Displays
  • Fast Clean Switching With Simultaneous Multiview Source Combining On The Wall
  • PiP, PoP, Quad-View, And Custom Layout Modes For Versatile Content Presentation
  • Bezel Correction And Picture Adjustment Enable Precise Multi-Display Calibration
  • HDCP 2.2 Compatibility Ensures Secure Handling Of Protected Source Content
  • Dual Built-In Power Supplies Deliver Redundancy For Mission-Critical Deployments
  • Multiple Control Interfaces Including Web UI, Telnet, And Serial For System Integration
Log in or register for YOUR best price

The Kramer VW-9 is engineered for AV integrators, control room designers, and production teams who need a single processor to manage high-density video wall deployments. With four HDMI 2.0 inputs and ten HDMI 2.0 outputs, the VW-9 accommodates virtually any wall configuration — 1x10, 2x5, 3x3, 5x2, and beyond — making it adaptable across boardrooms, broadcast environments, command centers, and large-venue installations.

Where the VW-9 distinguishes itself from simpler matrix switchers is in its multiviewer intelligence. Operators can run PiP, PoP, quad-view, and fully customized screen layout configurations simultaneously across the wall, with fast and clean switching between input channels. Input and output resolution supports 4K at 60Hz with 4:4:4 color sampling and up to 18 Gb/s data rate, ensuring no compromise on image fidelity even on large-format displays. Bezel correction and picture adjustment options allow precise calibration for any physical display array.

For system integrators managing complex control infrastructure, the VW-9 offers RS-232, RS-485, RS-422, Ethernet, and Telnet control — plus a web UI that simplifies remote configuration without requiring on-site access. Analog stereo audio output supplements embedded HDMI audio for installs where routing audio independently from video is required. Dual built-in power supplies provide the redundancy expected in mission-critical environments where downtime is not an option.

Downloads

View full details

Specifications

Connectivity
Inputs
4x HDMI (HDMI 2.0)
Outputs
10x HDMI (HDMI 2.0)
Serial I/O
1x DB-9 (RS-232) Input/Output
RS-422/RS-485 I/O
1x Block 5-Pin (RS-422/RS-485) Input/Output
Network
1x RJ45 (10/100 Mbps Ethernet)
Video
Video Format
HDMI
Max Resolution (4096 x 2160)
50/60 fps
Max Resolution (3840 x 2160)
30/50/60 fps
Maximum Data Rate
18 Gb/s
Color Sampling
4:4:4
HDCP Support
Yes
HDR Support
No
EDID Support
No
Audio
Audio Output
Stereo Analog
Power
Power Input
2x IEC C14
Input Voltage
100 to 240 VAC
Dimensions
Product Dimensions (W x D x H)
17.3" x 10.4" x 16.6"
Product Dimensions (mm)
440.0 x 264.0 x 421.0 mm
Weight
Product Weight
32.6 lbs
Shipping
Package Dimensions (L x W x H)
20.4" x 20.2" x 15.1"
Package Weight
43.635 lbs
