• Listen Technologies LR-4200-216 Intelligent DSP RF Receiver
1 4

Listen Technologies LR-4200-216 Intelligent DSP RF Receiver | 216 MHz

Listen Technologies LR-4200-216 Intelligent DSP RF Receiver | 216 MHz

SoundPro Item: 73026 | Part Number: LR-4200-216

$209.00
$239.00 $209.00
Your Price Sold out
MSRP: $239.00 | MAP: $209.00

Usually ships in 5-7 business days

  • High Performance RF Sensitivity Captures Signals In Challenging Venue Environments
  • Integrated Digital Signal Processing Loop Driver Enhances T-Coil Audio Quality
  • Dual Output Jacks Enable Two Users To Share A Single Receiver Unit
  • Micro USB Connectivity Simplifies Charging And Firmware Updates Without Proprietary Hardware
  • Rechargeable Lithium-Ion Cells Eliminate Disposable Battery Replacement Costs
  • OLED Screen Provides At-A-Glance Channel And Battery Status Information
Log in or register for YOUR best price

Designed for venues that demand reliable assistive listening without burdening users or staff, this receiver combines best-in-class RF sensitivity with a pocket-sized profile that simplifies distribution and storage. The integrated lanyard doubles as a neck loop with digital signal processing circuitry, providing T-coil users a cleaner audio path than passive induction accessories. Dual headphone jacks enable two listeners to share one unit during guided tours or side-by-side training sessions.

Installation teams benefit from micro USB connectivity that supports both charging and firmware updates through standard ports, eliminating proprietary docking hardware. The OLED screen displays channel selection, volume, and charge level without requiring the user to navigate complex menus. Lithium-ion cells deliver eight-hour runtime and recharge fully in two hours, reducing the operational cost and environmental impact of disposable batteries.

Built for lecture halls, conference centers, and worship spaces operating in the 216 MHz spectrum, this receiver balances portability with the RF performance required for large-venue coverage. Its sub-three-ounce weight and belt clip option make it unobtrusive for attendees who need amplification throughout extended programs.

Downloads

View full details

Specifications

Certifications
Compliance Standards
FCC Part 15, Part 90, Industry Canada, RoHS
Dimensions
Unit (H x W x D)
3.75 x 2.0 x 0.64 in. (9.6 x 5.0 x 1.7 cm)
With Belt Clip (H x W x D)
3.75 x 2.0 x 0.80 in. (9.6 x 5.0 x 2.1 cm)
Dimensions (H X W X D)
3.75 x 2 x 0.64 inches (9.6 x 5 x 1.7 cm)
Weight
Unit Weight
1.6 oz (45.4 g)
Unit Weight With Batteries
2.4 oz (68.1 g)
Shipping Weight
3.2 oz (90.8 g) with 16 oz (454 g) minimum
Electrical
Battery Charging
Time Fully charged in 2 Hours
Audio
Frequency Response
50 Hz - 15 kHz (±3 dB)
Total Harmonic Distortion
< 2% THD at 80% deviation
Signal To Noise Ratio
70 dB (SQ enabled), 50 dB (SQ disabled)
Output Connectors
Two (2) 3.5 mm unbalanced, 0 dBu nominal, 16 mW maximum
Output Impedance
32 ohm
System Distortion
< 2% total harmonic distortion (THD) at 80% deviation
System Frequency Response
50 Hz - 15 kHz (±3 dB)
System Signal to Noise Ratio
SQ enabled 70 dB, SQ disabled 50 dB
Connectivity
Output/s
Two (2) 3.5 mm (0.14 in.) connectors, unbalanced, 0 dBu nominal output level, 16 mW maximum, impedance 32 ohm
Construction
Color
Dark Grey
Controls
User Controls
Power, up/down volume
Channel Selection
Press and hold volume buttons for 5 seconds, use up/down to select
Programming
Via software and USB port
Set-up Controls
Press and hold up/down volume buttons for 5 seconds to enter channel adjust, use up/down to select channel
Included Items
Includes
One (1) LR-4200-216 receiver, quick start guide, non-proprietary field replaceable Lithium-ion battery
Environmental
Operating Temperature
14 to 104 ºF (-10 to 40 ºC)
Storage Temperature
-4 to 122 ºF (-20 to 50 ºC)
Relative Humidity
0 to 95% non-condensing
Operation Temperature
14 to 104 ºF (-10 to 40 ºC)
RF
Frequency Range
216.0125 - 216.9875 MHz
Number Of Channels
19 wide band, 38 narrow band
Sensitivity
0.6 µV typical, 1 µV maximum for 12 dB SINAD
Frequency Stability
± 0.005% (32 to 122 ºF / 0 to 50 ºC)
Squelch
Programmable in 20 steps, automatic on RF signal loss
Antenna Type
Earphone/neck loop lanyard or standard earphone cable
Frequency Accuracy
± .005% stability 32 to 122 ºF (0 to 50 ºC)
Power
Power Supply
Micro USB connector, 5 V, 500 mA
Battery Type
Lithium-ion, field replaceable
Battery Life
8 hours continuous use
Charging Time
2 hours to full charge
Indicators
LED
White, illuminated when on, flashes for low battery or charging, solid when fully charged
Display
OLED showing channel, battery level, unit number, charging status
LEDs
White, illuminated when unit is on, flashes when batteries are low or to indicate charging, solid when fully charged
Compliance
Standards
FCC Part 15, Part 90, Industry Canada, RoHS
Physical
Dimensions with Belt Clip
3.75 x 2 x 0.8 inches (9.6 x 5 x 2.1 cm)
