Listen Technologies TILR03+ Induction Loop Receiver

Listen Technologies TILR03+ Induction Loop Receiver

SoundPro Item: 148351 | Part Number: TILR03+

$306.00
$335.00 $306.00
Your Price Sold out
MSRP: $335.00 | MAP: $306.00

Usually ships in 5-7 business days

  • Vertically Mounted Pickup Coil Emulates Hearing Aid Telecoil Response For Accurate User Experience Testing
  • Dual LED Field Strength Indicators Display Good And Marginal Signal Levels Per IEC60118-4 Thresholds
  • Selectable Low Cut Filter Simulates Hearing Aid Frequency Response From 400Hz To 6kHz
  • Auto Power Off Function Extends Battery Life Beyond 100 Hours On Two AA Cells
  • No Technical Training Required For Basic Loop System Coverage Verification
Log in or register for YOUR best price

The TILR03+ gives venue managers, integrators, and production staff a reliable way to verify induction loop assistive listening system performance without expensive test equipment. Built to IEC60118-4 international loop performance standards, it provides immediate visual and auditory confirmation that hearing loop coverage meets accessibility requirements in theatres, houses of worship, conference centers, and municipal facilities.

The vertically mounted pickup coil and selectable low-cut filter emulate a hearing aid switched to telecoil mode, letting technicians hear exactly what end users experience. Dual LED indicators show good and marginal field strength thresholds at the 400mA/m reference point, enabling installers to map coverage patterns, identify dead zones, and locate electromagnetic interference sources during commissioning and routine maintenance.

Designed for non-technical staff to perform regular system checks, the receiver includes a documented test procedure that requires no specialized training. With over 100 hours of battery life and automatic shutoff when headphones are removed, it serves as both a deployment tool for contractors and an ongoing monitoring resource for facility operators responsible for ADA Title III compliance.

Downloads

View full details

Specifications

Certifications
Safety and EMC
CE marked to all relevant standards
Dimensions
Width
62mm
Depth
26mm
Height
112mm
Audio
Frequency Response Standard
Flat 85Hz – 6kHz ± 0.5dB
Frequency Response Low Cut
400Hz – 6kHz – 3dB
Output Power
>100mW into 16Ω load
Distortion
< 2% THD+N
Magnetic Field Strength
To PPM type II referenced to 400mA/m rms
Connectivity
Stereo Headphones Impedance
32Ω per side (included)
Electrical
Battery Life
>100 hours with (2) AA Alkaline batteries
Environmental
Temperature Range
-10 to 45ºC
Humidity Range
20 to 90% relative humidity
Ingress Protection
IP20
Included Items
Includes
One (1) ILR3+ Induction Loop Receiver, One (1) Lightweight Stereo Headphone, One (1) Handbook, One (1) User Guide, Two (2) AA Batteries
