Specifications
Driver
Cone Size
8"
Power Handling
15W
Magnet
10 oz. ceramic
Voice Coil
1 in. copper
Cone Material
Cotton cloth treated with phenolic resin and acrylic lacquer coating
Transformer
None
Construction
Frame
20-gauge stamped steel with zinc plating
Dimensions
Mounting Depth
2.84"
Mounting Bolt Circle
7.625"
Performance
Frequency Response
77Hz-7.5kHz (+-6dB) and 50Hz-20kHz (+-18.3dB)
Dispersion Angle
90 degrees conical
Average Sensitivity
96.7 dB
Identifiers
MPN
8C10MRB
