Specifications
Driver
Driver Size
8"
Driver Type
Single cone
Power Handling
15W
Magnet Weight
10 oz.
Voice Coil
1" copper voice coil
Cone Material
Cotton cloth treated with phenolic resin and coated with acrylic lacquer
Frame
Frame Construction
20-gauge stamped steel
Frame Finish
Zinc-plated
Transformer
Transformer Voltages
25V/70V dual voltage
Transformer Taps
0.25W, 0.5W, 1W, 2W, 5W
Performance
Frequency Response
75Hz-7.5kHz (±6dB) and 50Hz-20kHz (±17.8dB)
Average Sensitivity
96.8 dB
Dispersion Angle
90 degrees conical
Dimensions
Mounting Depth
2.84"
Mounting Bolt Circle
7.625"
