Lowell CS650-DW 50W Mono Volume Control and Program Selector

Lowell CS650-DW 50W Mono Volume Control and Program Selector

SoundPro Item: 86551 | Part Number: CS650-DW

$142.21
$161.60 $142.21
Your Price Sold out
MSRP: $161.60 | MAP: $142.21

Usually ships in 5-7 business days

  • Autoformer Attenuator Design Provides Accurate Level Control Without Signal Degradation
  • Compatible With 70V and 25V Speaker Lines For Wide Distributed Audio System Support
  • Six-Source Non-Shorting Rotary Selector Ensures Complete Isolation Between Program Lines
  • Plug-In Screw Terminations On Volume Control Simplify Prewire And Field Connection
  • Euro-Style Screw Terminals Allow Independent Or Combined Installation Of Each Section
  • Includes 2-Gang And Two 1-Gang Decorator Wall Plates For Flexible Mounting Options
Log in or register for YOUR best price

The Lowell CS650-DW is a combination wall unit designed for installed audio applications where zone control and source selection are required at a single location. The autoformer-style 50W volume control provides 33dB of attenuation across 10 steps and is compatible with both 70V and 25V speaker distribution lines, making it well suited for commercial installs such as restaurants, retail spaces, houses of worship, and corporate AV systems. The six-source rotary program selector operates on a two-pole, non-shorting design, ensuring complete isolation between source lines during switching.

Euro-style screw terminals on the selector and plug-in screw terminations on the volume control simplify field wiring and allow each section to be installed together or independently across separate locations. The package includes a 2-gang decorator wall plate and two 1-gang decorator wall plates, giving integrators the flexibility to co-locate or distribute the controls across a room. For AV integrators and system contractors handling multi-zone distributed audio, the CS650-DW eliminates the need for separate volume and source-selection hardware at each listener position.

Downloads

View full details

Specifications

Audio
Power Handling
50W
Attenuation
33dB
Attenuation Steps
10
Final Steps Before Off
6dB each (33dB total)
Compatible Speaker Lines
70V, 25V
Controls
Volume Control Type
Autoformer attenuator
Selector Switch Type
Two-pole, non-shorting rotary
Selector Sources
6
Connectivity
Volume Control Wiring
Plug-in screw terminations
Selector Switch Wiring
Euro-style screw terminals
Construction
Color
White
Dimensions
2-Gang Wall Plate
4.562" x 4.5" x 2.125"
Included Items
Wall Plates
2-gang decorator plate, two 1-gang decorator plates
Hardware
Knob and mounting screws
Identifiers
MPN
CS650-DW
