Specifications
Dimensions
Dimensions (HxDxW)
12.5" x 3.2" x 14"
Electrical
THD, Mic Pre @ Insert
<0.0007%
Power Consumption
25 watts
Audio
Frequency Response
Mic input to main output (gain @ unity), +0, -1 dB, 20Hz to 50kHz, +0, -3dB, <10Hz to >100kHz
EIN (mic Input to Insert Send Out, Max gain)
150Ω termination: -128.5 dBu 20Hz - 20kHz
Connectivity
All Other Inputs
+22 dBu
Main Mix XLR Out
+28 dBu
All Other Outputs
+22 dBu
Construction
Channel Insert Return
2.5 kΩ
Environmental
Operating Temperature
32°F to 104°F (0°C to 40°C)
Shipping
Weight
9.5 pounds
General
Main Mix Noise
20Hz - 20kHz bandwidth, 1/4" main out, channels 1-6 gain @ unity, channel EQs flat, all channels assigned to main mix, channels 1 3 and 5 panned left, 2 4 and 6 panned right, Main Mix Fader @ Unity, Channel Faders @ Unity: -86 dBu
Main Mix Fader Down, Channel Faders Down
-101 dBu
Main Mix @ Unity, Channel Faders Down
-91 dBu
Attenuation / Crosstalk
1kHz relative to 0 dBu, 20Hz - 20kHz bandwidth, line in, 1/4" main out, gain @ unity
Main Mix Fader Down
-100 dBu
Channel Alt / Mute Switch Engaged
-90 dBu
Channel Fader Down
-90 dBu
CMRR (1kHz)
better than -70 dB
Mic in
+22 dBu
Tape in
+16 dBu
Tape Out
1.1 kΩ
High Shelving
±15 dB @ 12kHz
Mid Peaking
±15 dB @ 2.5kHz
Low Shelving
±15 dB @ 80Hz
US, JP
100-120 VAC, 50-60Hz
Fuse Rating (100-120V)
500mA slo blo, 5 x 20 mm
