Specifications
Dimensions
Diameter
12"
Voice Coil Diameter
3"
Diaphragm Diameter
1.75"
Horn Exit Diameter
1"
Mouth Size (WxH)
12" x 7"
Dimensions (HxWxD)
26.1" x 16" x 14.8"
Audio
Max. SPL Long-Term
123 dB @ 1m
Crossover Point
1800 Hz
Input Impedance
8 Ω
Connectivity
Input / Thru Connector Type
Speakon-style NL-4 jack, 1/4" TS jack
Construction
Magnet Material
ferrite
Diaphragm Material
heat treated titanium
Material
polypropylene
Handles
one on each side, one on top
Grille
perforated metal with weather-resistant coating
Environmental
Operating Temperature Range
14°F to 113°F (-10°C to 45°C)
Shipping
Weight
46 pounds
General
Frequency Response (-3 dB)
55Hz - 18,000Hz
Frequency Range (-10 dB)
45Hz - 20,000Hz
Low-Frequency Crossover Type
24 dB / octave, time offset corrected
High-Frequency Crossover Type
24 dB / octave
RMS
300 watts
Music
500 watts
Peak
750 watts
Type
conical and exponential
Horizontal Coverage
90° (1kHz - 20kHz)
Vertical Coverage
45° (2.8kHz - 20kHz)
Over-Excursion Protection
second-order high-pass filter
Driver Protection
dynamic protection for compression driver
Basic Design
asymmetrical trapezoidal
