Specifications
Dimensions
Dimensions (HxWxD)
25" x 14.7" x 16.2"
Electrical
1/4" TS, Wide-Z Impedance
1MΩ unbalanced
Mix Out Impedance
600Ω balanced
Audio
Max SPL Peak
134 dB
Crossover Type
24dB/octave
Crossover Frequency
1.5kHz
Connectivity
Main Output EQ
3-band
Input / Output
Input type
Mic-line Impedance
8kΩ balanced
AC Connector
3-pin IEC 250VAC, 10A male
Shipping
Weight
42 pounds (19.1 kg)
General
Coverage (HxV)
90° x 60°
Monitor Angle
50°
Low Frequency
12"
Mid Frequency
6.5"
High Frequency
1.4"
System
1600 watts peak
Low Frequency Power Amplifier
1220 watts peak
High Frequency Power Amplifier
380 watts peak
Amplifier Design
Class D
Voicing
4 speaker modes
Subwoofer HPF
off, DRM18S, var
Delay
0-100ms
Direct Out and Mix Out
male XLR balanced
RF
Frequency Range
50Hz - 20kHz (-3 dB); 45Hz - 20kHz (-10 dB)
