Mackie ONYX12 12-Channel Analog Mixer with Multitrack USB
Mackie ONYX12 12-Channel Analog Mixer with Multitrack USB
SoundPro Item: 109731 | Part Number: ONYX12
In stock and ready to ship
- 14x4 analog mixer with 4 low-noise Onyx preamps that provide 60dB of gain
- 3-band British-Style Perkins EQ with On/Off hard bypass switch for dialing in the perfect tone
- High-resolution multitrack recording to Mac/PC via USB at up to 24-Bit / 96 kHz
- Stereo recording directly to an SD card
- Professional, customizable Dynamic FX, with Multi-Parameter Adjustment
- Studio Command—full-color LCD for easy FX control and SD card management
- Bluetooth®-enabled for streaming music directly into any channel, with streamed audio routed to Aux Sends or Main Mix
- Switchable hi-Z inputs for guitars, bass, and other instruments
- Built-Like-A-Tank™ rugged steel chassis for added protection
Give your project studio or mobile rig the analog mixer it deserves. The Mackie Onyx12 is a premium 12-channel USB mixer optimized for multitrack recording and live sound. Experience impeccable sound quality, a flexible FX engine and seamless workflow for your home recording or live shows.
Record ultra-clean, transparent sound with incredible accuracy. Mackie's award-winning Onyx Mic Preamps are designed for maximum studio-quality performance. Create podcasts, live stream gameplay, or produce the next hit. No matter what you do, you deserve to sound great.
The Mackie Onyx12 features an enhanced 3-Band “British Style” Perkins EQ based on the same circuit used on classic mixing consoles from the ‘60s and ‘70s. This version designed by Mackie offers greater filter control, minimum phase shift and allows you to pinpoint specific frequency ranges. Creating the Perkins EQ started with the Wien Bridge circuit topology, then determined capacitor and resistor values to give the EQ an extra 6dB (±15dB) of control without excessively narrowing the "Q" or bandwidth of the filters.
The more plugins the better, right? Get creative and customize your sound with professional built-in effects. The professional high-resolution FX processor gives you limitless control over a robust collection of unique digital effects, including a dedicated equalizer to shape your mix to perfection.
It's important to feel in control of your workstation. The Mackie Onyx12 features powerful full-color LCDs with dedicated physical transport controls. Apply FX and recall up to six customizable presets using an intuitive single-knob interface. Record a stereo mix, browse files and play music direct to/from an SD card, all via Studio Command.
Carry and transport your Mackie Onyx12 mixer effortlessly with its QuickGrip side handles. Whether you’re moving gear around your home studio or heading to rehearsal, the rugged design of our steel chassis and sealed rotary will protect your investment wherever you go.
- Noise Characteristics
- EIN (150Ω source impedance, 20Hz to 20kHz) mic in to insert send out, max gain: -128dBu
- Residual Output Noise
- All outputs, master levels off, all channel levels off: -98 dBu
- All outputs, master levels unity, one channel level unity: -88 dBu
- Frequency Response Mic Input to Any Output (gain at unity +0dB/-1dB)20Hz to 30,000Hz
- Distortion (22Hz to 80kHz bandwidth) Mic In to Main Out (+4dBu output)<0.01%
- Attenuation and Crosstalk
- Adjacent Inputs @ 1kHz: -90 dB
- Inputs to Outputs @ 1kHz: -80 dB
- Fader Off @ 1kHz: -85 dB
- Mute Switch @ 1kHz: -90 to -100 dB
- CMRR (mic in to main out, max gain, 1kHz)70 dB
- Max. Levels
- All Inputs: +22 dBu
- Main Mix XLR: +28 dBu
- All Other Outputs: +22 dBu
- Impedances
- Mic In: 3.3 kΩ
- Channel Insert Return: 10 kΩ
- All Other Inputs: ≥20 kΩ
- Phones Out: 25 Ω
- All Other Outputs: 120 Ω (unbalanced), 240 Ω (balanced)
- Equalization
- All channels (except 1/8" stereo channel)
- Low: ±15 dB @ 80Hz
- Mid (mono channels): ±15 dB 100Hz - 8kHz
- Mid (stereo channels): ±15 dB @ 2.5kHz
- High: ±15dB @ 12kHz
- Low Cut Filter: ±18 dB/octave @ 100Hz
- Digital Effect Presets12
- Meters, Main L/R Mix
- Two Columns of 12 Segments Each: 0L, +15, +10, +6, +3, 0 (0dBu), -2, -4, -7, -10, -20, -30
- USB
- Format: USB 2.0
- I/O: multiple inputs, 2x2 stereo outputs
- A/D/A: 24 bit, 44.1kHz, 48kHz, 96kHz
- SD2x2 / 24-bit / 96kHz
- Phantom Power48 VDC to all mic channels simultaneously
- AC Power Requirements
- Power Consumption: 40 watts
- Universal AC Power Supply: 100-240VAC, 50-60Hz
- Power Connector: 3-pin IEC line cord
- Dimensions (HxWxD)5.4" x 14.8" x 14"
- Weight13 pounds
