Mackie ProFX10v3+ 10-Channel Analog Mixer

Mackie ProFX10v3+ 10-Channel Analog Mixer

SoundPro Item: 141760 | Part Number: ProFX10v3+

$329.99
$329.99 $329.99
Your Price Sold out
MSRP: $329.99 | MAP: $329.99

Usually ships in 5-7 business days

  • 4 Onyx mic pres with up to 60 dB of gain and ultra-low noise performance
  • High-resolution GigFX+ effects engine
  • Full-color LCD display for editing and saving effects presets
  • 24-Bit/192kHz 2x4 USB-C audio-interface
  • Three recording modes: Standard, Loopback, and Interface
  • Bi-directional Bluetooth for music playback and caller integration
  • 3-band EQ on all channels
  • One-knob compression on channels 1 and 2
  • Hi-Z switches allow direct connection of instruments
  • 100Hz low-cut filter and 48V phantom power on all mic channels
  • Stereo 1/8” input on channel 9/10
  • Headphone output with separate level and blend control
  • Easily blend between monitoring your computer output and a latency-free feed from the mixer
  • Waveform OEM recording software included
  • Legendary Built-Like-A-Tank design
  • Solid steel chassis
Log in or register for YOUR best price

The Mackie ProFX10v3+ 10-Channel Analog Mixer is the ultimate affordable solution for live sound, home recording, and content creators. Now with Onyx mic preamps that offer 60dB from headroom, everything from gain-hungry mics to guitars will sound better than ever. and you can keep it all in check with easy single-knob compression. The new GigFX effects engine offers 24 built-in FX for even more options for adding the finishing touch. Record your tracks in 24-Bit/192kHz quality with 2x4 USB I/O with zero-latency hardware monitoring for easy overdubs. Both ProTools | First and Waveform OEM recording software/plugin packages are included.

View full details

Specifications

Electrical
Power Consumption
30W (ProFX12v3+)
Universal AC Power Supply
100-240VAC, 50-60Hz
Audio
Frequency Response
Mic input to any output (gain at unity, +0dB/-dB): 20Hz to 30kHz
Low Cut Filter
±18dB/octave @100Hz
Output
70dB
Phantom Power
48 VDC to all Mic channels simultaneously
Connectivity
Adjacent Inputs @1kHz
-90dB
Inputs to Outputs @1kHz
-80dB
All Inputs
+22dBu
Main Mix XLR
+28dBu
All Other Outputs
+22dBu
All Other Inputs
≥20kΩ
Channel to Insert Output
60dB¼”
Main Output
80dBXLR
Sub Output
80dBAux
Output (Pre-Fader)
80dBAux
Output (Post-Fader)
90dBFX
USB Input to
XLR Main Output – 46dB
Power Connector ProFX6v3+, ProFX10v3+)
12VDC @ 2A Class I Hard-Wired Wall Mount AdapterProFX12v3+: 3-Pin IEC Line Cord
Construction
Channel Insert Return
10kΩ
General
Noise Characteristics
Equivalent Input Noise (EIN), 150Ω Source Impedance, 20Hz to 20kHz) Mic in to Insert Send out, max gain: -126dBu, Residual Output Noise All outputs, master levels off, all channel levels off: -95dBuAll outputs, master levels unity, one channel level unity: -80dBu
Distortion (22Hz to 80kHz bandwidth)
Mic in to Main Out (+4dBu output): <0.03%
Fader Off @1kHz
-75dB
Mute Switch/Break Switch Mute @1kHz
-90dB
Common Mode Rejection Ratio (CMRR)
Mic in to Main out, max gain, 1kHz: 70dB
Mic in
3.3kΩ
Phones Out
25Ω
Low
±15dB @80Hz
Mid
±15dB @2.5kHz
High
±15dB @12kHz
Send
90dBFX Send (ProFX10v3+): 80dBUSB
Digital Effects
Number of Presets: 12
Meters
Main L/R Mix, All other ProFXv3+ mixers – Two columns of 12 segments each: 0L, +15, +10, +6, +3, 0 (0dBu), -2, -4, -7, -10, -20, -30
ProFX6v3+ - Two Columns of 8 Segments Each
0L, +14, +8, +4, 0 (0dBu), -4, -12, -24
Format
USB 2.0
I/O
1 Stereo Input, 2 Stereo Outputs
A/D/A
24 bit, 44.1kHz, 48kHz, 96kHz, 192kHz
ProFX6v3+ HxWxD
2.9x7.5x8.4” (74x191x213mm)Weight: 2.6lbs (1.2kg)
ProFX10v3+ HxWxD
3.3x10.7x11.9” (84x272x302mm)Weight: 4.9lbs (2.2kg)
ProFX12v3+ HxWxD
4x13x14.8” (102x330x376mm)Weight: 7.9 lbs (3.6kg)
