Specifications
Dimensions
Dimensions (HxWxD)
2.9" x 7.5" x 8.4"
Audio
Frequency Response
20Hz - 30kHz (mic input to any output gain at unity, +0dB/-1dB)
Low Cut Filter
18dB/octave @100Hz
Phantom Power
48VDC to all mic channels simultaneously
Connectivity
Line Inputs
10
Mic Inputs
4
USB I/O
2x4
All Inputs
+22dBu
Main Mix XLR
+28dBu
All Other Outputs
+22dBu
All Other Inputs
>20kΩ
USB Format
USB 2.0
Construction
Channel Insert Return
10kΩ
Shipping
Weight
2.6 pounds (1.2 kg)
General
Compressors
2
Distortion 22Hz to 80kHz Bandwidth
<0.03% (mic in to main out +4dBu output)
Common Mode Rejection Ratio
70dB (mic in to main out, max gain, 1kHz)
Mic in
3.3kΩ
Phones Out
25Ω
Low
+/-15dB @80Hz
Mid
+/-15dB @2.5kHz
High
+/-15dB @12kHz
Digital Effect Presets
24
