Specifications
Dimensions
Dimensions (HxWxD)
4.4" x 32.3" x 17.1"
Electrical
Max. Voltage Gain (EQ Flat)
Mic Input Channel to, Mono Line Input Channel to, Stereo Line Input Channel to, 1/8" Input to
Power Consumption
50 watts
Universal AC Power Supply
100-240VAC, 50-60Hz
Audio
Mic in to Insert Send Out, Max Gain
-128dBu
Frequency Response
Mic Input to Any Output (gain at unity, +0dB/-1dB): 20Hz to 30,000Hz
Distortion
(22Hz to 80kHz bandwidth)
Mic in to Main Out, Max Gain, 1kHz
70 dB
Low Cut Filter
18 dB/octave @ 100Hz
Phantom Power
48 VDC to all mic channels simultaneously
Connectivity
Mic in to Main Out (+4 Dbu output)
<0.01%
Adjacent Inputs @1kHz
-90dB
Inputs to Outputs @1kHz
-80dB
All Inputs
+22dBu
Main Mix XLR
+28dBu
All Other Outputs
+22dBu
All Other Inputs
≥20kΩ
USB Input to XLR Main Output
46 dB
Power Connector
3-pin IEC line cord
Construction
Channel Insert Return
10kΩ
Shipping
Weight
26.5 pounds
General
Noise Characteristics
EIN (150Ω source impedance, 20Hz to 20kHz), Residual Output Noise
Fader Off @1kHz
-75dB
Mute Switch/Break Switch Mute @1kHz
-100dB
Mic in
3.3kΩ
Phones Out
25 Ω
Equalization
All Channels (except 1/8" stereo channel)
Low
±15 dB @ 80Hz
Mid
±15 dB 100Hz - 8kHz
High
±15 dB @ 12kHz
Number of Presets
24
Meters
Main L/R Mix
Two Columns of 12 Segments Each
0L, +15, +10, +6, +3, 0 (0dBu), -2, -4, -7, -10, -20, -30
Format
USB 2.0
I/O
1 stereo input, 2 stereo outputs
A/D/A
24 bit, 44.1kHz, 48kHz, 96kHz, 192kHz
