Specifications
Dimensions
Dimensions (HxWxD)
26.5" x 23" x 19.5"
Electrical
Rated THD
<1%
1/4" Hi-Z Impedance
1 MΩ unbalanced
Mix Out Impedance
600 Ω balanced
Audio
Max. SPL Peak
118 dB
Crossover Frequency
600Hz (18 dB butterworth)
Connectivity
Input / Output
Input Type
Mic-Line Impedance
8 kΩ balanced
AC Connector
3-Pin IEC 250VAC, 10 A male
Construction
Enclosure Material
polypropylene
Enclosure Finish
black polyurea
Grille Material
perforated steel
Grille Finish
powder-coated black
Shipping
Weight
37 pounds
General
-10 Db
40Hz - 20,000Hz
-3 Db
50Hz - 20,000Hz
Coverage (HxV)
90° x 50°
Low Frequency
10" with ferrite
High Frequency
6 x 2" silk dome tweeters
Rated Power
1300 watts peak
Design
Class D
Voicing
3 speaker modes
Reverb
off, 1 (short), 2 (medium), 3 (long)
Low
+5 / -15 dB @ 90Hz
High
+5 / -15 dB @ 6kHz
Mix Out
male XLR balanced
Detachable Line Cord
~100 - 240VAC, 50-60Hz, 110W
Power
Power Supply Type
switchmode
