Specifications
Dimensions
Dimensions (HxWxD)
28.8" x 17.6" x 15.4"
Electrical
1/4" Hi-Z Impedance
100 kΩ balanced
Mix Out Impedance
300 Ω balanced
Audio
Frequency Response
40Hz - 20kHz (-10 dB); 44Hz - 20kHz (-3 dB)
Max. SPL Peak
136 dB
Crossover Type
24 dB/octave
Crossover Frequency
2 kHz
Connectivity
Input EQ
3-band
Input / Output
Input Type
Mic-Line Impedance
20 kΩ balanced
Line Input Power
Detachable Line Cord
AC Connector
3-pin IEC 250 VAC, 10 A male
Construction
Enclosure Material
black polypropylene
Enclosure Finish
light black texture
Grille Material
16-18 gauge perforated steel w/ nylon net backing
Grille Finish
powder-coated black
Shipping
Weight
48.9 pounds
General
Coverage (HxV)
90° x 60°
Monitor Angle
45°
Low Frequency
15" with ferrite
High Frequency
1.4" polymer compression driver
System Power Amplification, Rated Power
2000 watts peak
Power Amplifiers
Low Frequency Power Amplifier, High Frequency Power Amplifier
Voicing
10 speaker modes (5 inside, 5 outside)
Subwoofer HPF
off, DRM18S, Var
Delay
0-100 ms
Direct Out and Mix Out
male XLR balanced
Power
Power Supply Type
switchmode
