Specifications
Acoustic Performance
Frequency Response (-10 dB): 32 Hz - 152 Hz
Frequency Response (-3 dB): 39 Hz - 100 Hz
Maximum SPL Peak: 123 dB
Frequency Response (-3 dB): 39 Hz - 100 Hz
Maximum SPL Peak: 123 dB
Transducers
Low Frequency: 2x 8 in / 203 mm custom woofer
Power Amplifiers
System Power Amplification
- Rated Power: 400 watts peak
- Rated Power: 400 watts peak
- Rated THD: < 1%
- Cooling: Convection
- Design: Class D
Input / Output
Input Type: 2x Female XLR- 1/4" balanced TRS combo jack and Bluetooth 5.4
Mic/Line Impedance: 600 Ω Balanced
Output: 2x Male XLR Balanced
High Pass Mode: Full Range, High Pass
Output Mode: Stereo / Mono
Phase: Normal / Invert
Output Impedance: 1 ΜΩ
Mic/Line Impedance: 600 Ω Balanced
Output: 2x Male XLR Balanced
High Pass Mode: Full Range, High Pass
Output Mode: Stereo / Mono
Phase: Normal / Invert
Output Impedance: 1 ΜΩ
Bluetooth Information
Bluetooth Protocol: 5.4
Bluetooth Function: Audio streaming
Bluetooth Function: Audio streaming
Line Input Power / GB-200 Rechargeable Battery Information
Detachable line cord:100-240V-, 50-60 Hz, 75W
AC Connector: 3-pin IEC 250 VAC, 10 A male
Power Supply Type: Switchmode
Battery Type: Lithium lon
Battery Life: Up to 12 hours
(6 hours per battery)
Charge Time: - 3 hours
Capacity: 8880 mAh
Nominal Voltage: 11.1 V
Battery Compartments: Two (hot-swappable)
Operating Temperature Range: -10-+45℃ //14-113°F
Charging Temperature Range: 0-+45 ℃ // 32- 113°F
AC Connector: 3-pin IEC 250 VAC, 10 A male
Power Supply Type: Switchmode
Battery Type: Lithium lon
Battery Life: Up to 12 hours
(6 hours per battery)
Charge Time: - 3 hours
Capacity: 8880 mAh
Nominal Voltage: 11.1 V
Battery Compartments: Two (hot-swappable)
Operating Temperature Range: -10-+45℃ //14-113°F
Charging Temperature Range: 0-+45 ℃ // 32- 113°F
