Specifications
General
RMS output power
2500 W
Amp class
Class D
Max. SPL peak (pink noise, halfspace/1 m, CF 4)
137 dB
Max. SPL average (sine burst, BW, halfspace/1 m, THD≤10 %)
132 dB
Low frequency limit (-6 dB, rel. Avg.)
33 Hz
Number of inputs
1
Input connector types
XLR 3-pole female
Number of outputs
1
Output connector types
XLR 3-pole male
Protection features
Limiter, Overheating, Overload
Colour
Black
Bluetooth®
Bluetooth® version
Bluetooth® 5.0
Features
App control
Line input performance
Input impedance (balanced)
20,000 Ω
Signal processing
Mixer
No
Audio processing
Fully parametric 10-band EQ, Delay Line, Presets
AD/DA converter bit depth
24 Bit
AD/DA converter sampling rate
48 kHz
Bass driver
Size
15 "
Quantity
2
Magnet
Neodymium
Voice coil
4 "
Mains operation
Operation voltage
100 V AC - 240 V AC / 50 - 60 Hz
Power supply type
Switched-mode power supply (SMPS)
Rated power
1,300 W
Mains connector
Mains socket indoor power in male & powerCON®
Housing
Design
Bandpass
Number of handles
6
Cabinet material
Birch multiplex
Material thickness
18 mm
Coating
Polyurea
Front grille material
Aluminium
Cooling
Cooling system
Convection cooling
Environmental
Ambient temperature
0 - 40°C
Maximum air humidity (non-condensing)
80 %
Dimensions & weight
Width
540 mm
Height
934 mm
Depth
803 mm
Weight
89.8 kg
Other properties
Included accessories
Mains cable
