Specifications
General
RMS output power
1250 W
Amp class
Class D
Max. SPL peak (sine burst, halfspace/1 m, THD≤10 %)
126 dB
Max. SPL peak (pink noise, halfspace/1 m, CF 4)
132 dB
Max. SPL average (sine burst, BW, halfspace/1 m, THD≤10 %)
124 dB
Low frequency limit (-3 dB, rel. Avg.)
37 Hz
Low frequency limit (-6 dB, rel. Avg.)
34 Hz
Low frequency limit (-10 dB, rel. Avg.)
31 Hz
Number of inputs
1
Input connector types
XLR 3-pole female
Number of outputs
1
Output connector types
XLR 3-pole male
Protection features
Limiter, Overheating, Overload
Colour
Black
Bluetooth®
Bluetooth® version
Bluetooth® 4.2
Features
App control
Signal processing
Audio processing
Fully parametric 10-band EQ, Delay Line, Presets
AD/DA converter bit depth
24 Bit
AD/DA converter sampling rate
48 kHz
Bass driver
Size
15 "
Magnet
Neodymium
Voice coil
4 "
Mains operation
Operation voltage
100 V AC - 240 V AC / 50 - 60 Hz
Power supply type
Switched-mode power supply (SMPS)
Mains connector
Mains socket indoor power in male & powerCON®
Housing
Design
Bass reflex
Number of handles
3
Cabinet material
Birch multiplex
Coating
Polyurea
Cooling
Cooling system
Convection cooling
Environmental
Ambient temperature
0 - 40°C
Maximum air humidity (non-condensing)
80 %
Dimensions & weight
Width
540 mm
Height
474 mm
Depth
761 mm
Weight
38 kg
