Specifications
Dimensions
Maximum Height
64.76 in
Min Height
16.14 in
Closed Length
32.68 in
Legs Tube Diameter
0.63- 0.98 in
Weight
Counterbalance Weight
8.82 lbs
Safety Payload Weight
15.43 lbs
Construction
Certifications
None
Color
Black
Material
Aluminum
Plate Type
504PLONG
Compatibility
Accessory Compatibility
MVAPANBARM; MVAPANBARL; 502HLV; 509HLV; 114MV; 181B; 165MV;
Included Items
Carrying Bag Included
110125
Pan Bar Included
Yes
Environmental
Maximum Working Temperature
140 °F
Minimum Working Temperature
-4 °F
Shipping
Weight
11.68 lbs
General
Safety Payload UNI/PdR 105:2021
22.05 lbs
Counterbalance System
Fixed
Bubble Spirit Level (No.)
1
Center of Gravity
2.17 in
Center Column
no center column
Top Attachment
1/4″ screw, 3/8″ screw
Ball Flat
75 Ball
Powered by (Batteries)
0
Easy Link
Yes
Front Tilt
-80° / +90°
Head Type
Video/Fluid Head
Leg Type
Twin
Leg Lock Type
Flip Lock
Leg Sections
3
Pan Drag
continuously adjustable from 0 to max level
Panoramic Rotation
360 °
Quick Release
Yes
Spreader
mid level - variable arm length with 'click stop' set positions
Tilt Drag
continuously adjustable from 0 to max level
