Martin Audio CDD12B

Martin Audio CDD12B

SoundPro Item: 30840 | Part Number: CDD12B

$1,750.00
$1,750.00 $1,750.00
Your Price Sold out
MSRP: $1,750.00 | MAP: $1,750.00

Usually ships in 5-7 business days

  • Compact, CDD™ passive two-way system
  • Coaxial Differential Dispersion™ technology
  • Elegant birch plywood enclosure
  • User-rotatable coaxial drive unit
  • Vertical and horizontal mounting options
  • Screw-free perforated steel grille
  • 8Ω nominal impedance
  • Discreet mounting accessories
  • Integral inserts for eyebolt suspension
  • Black or white standard colour options
Log in or register for YOUR best price

The CDD12 is a compact, passive two-way system designed for installations that require high output levels. Its high-specification 12" (300mm) LF /1" exit HF Coaxial Differential Dispersion driver delivers perfect sound across the audience over medium-throw distances.

View full details

Specifications

Type
Compact, high-output, Coaxial Differential Dispersion passive two-way system
Frequency Response
62Hz-20kHz ± 3dB, -10dB @ 50Hz
Driver
LF: 12” (300mm)/2.5” (63.5mm) voice coil, long excursion, shared ferrite motor with HF HF: 1” (25mm) exit/1.7” (44mm) voice coil, polyimide dome compression driver
Rated Power (2)
300W AES, 1200W peak
Sensitivity (8)
97dB
Maximum Spl (9)
122dB continuous, 128dB peak
Nominal Impedance
8Ω
Dispersion (-6Db)
110°-60° horizontal, 60° vertical (user-rotatable)
Crossover
1.9kHz passive
Enclosure
38 litre, birch plywood
Finish
Black or white textured paint
Protective Grille
Black or white perforated steel with scrim cloth backing
Connectors
Low profile 20A push-lock
Pin Connections
Left to right: Input+, Input -, Link -, Link+
Fittings
6 x M8 inserts for wall bracket 10 x M8 fly points
Dimensions
(W) 360mm x (H) 560mm x (D) 350mm (W) 14.17ins x (H) 22.05ins x (D) 13.78ins
Weight
19kg (41.89 lbs)
