Martin Lighting Exterior Projection Pro Compact Outdoor Projector | White

Martin Lighting Exterior Projection Pro Compact Outdoor Projector | White

SoundPro Item: 202183 | Part Number: MAR-90560251

$3,253.50
$3,615.00 $3,253.50
Your Price Sold out
MSRP: $3,615.00 | MAP: $3,253.50

Usually ships in 5-7 business days

  • Flat-Field Projection For Clean Image Quality
  • 5200 Lumens Across Zoom Range For Consistency
  • 15°-45° Zoom For Flexible Throw Coverage
  • DMX, RDM, And Stand-Alone For System Control
  • Hibernation Mode For Lower Idle Power Use
  • IP66, IK08, C5 Rating For Outdoor Reliability
  • Magnetic Sensor Access For Faster On-Site Setup
Log in or register for YOUR best price

The Martin Lighting Exterior Projection Pro Compact is a compact outdoor image projector built for permanent architectural, façade, and landscape applications where precise projection and dependable environmental protection matter. Its optical system maintains 5,200 lumens throughout the 15° to 45° zoom range, giving designers and integrators consistent output while dialing in projection coverage. The fixture supports control of zoom, focus, color, gobos, and animation, making it suitable for branded projections, textured building treatments, and site enhancement work.

For installation teams, the compact footprint, adjustable yoke, and dedicated connection compartments support cleaner integration in exterior environments. DMX, RDM, and stand-alone control options allow use in networked lighting systems or self-contained programmed deployments. Local access via magnetic sensor simplifies status checks and focusing on site, while hibernation mode helps reduce idle power draw in scheduled architectural systems.

The housing is designed for outdoor duty with IP66 ingress protection, IK08 impact resistance, and C5 corrosion resistance for demanding locations. A modular accessory approach allows the fixture to be configured with framing, animation, or gobo modules as required, helping specifiers adapt the projector to the application without changing the core fixture platform.

Downloads

View full details

Specifications

Physical
Length
342 mm (13.5 inch.)
Width
272 mm (10.7 inch.)
Height
335 mm (13.2 inch.)
Weight
12.5-13.9 kg (27.5–30.6 lbs) depending on actual configuration
Dynamic Effects
Color wheel
5 dichroic colors (red, green, blue, yellow, CTO) + open
Zoom
Motorized, 15° - 45° beam angle
Dimming
0-100% electronic
Shutter
Strobe and pulse effects, instant open and blackout
Focus
Motorized, variable 3 m (9.8 ft.) to infinity
Accessory 1-gobo module
indexing, variable rotation
Accessory 4-gobo module
selection, indexing, variable rotation
Accessory animation module
Continuous rotation with variable speed and direction (always in aperture)
Accessory Framing module
4 blades for manual adjustment of insert and angle (8 finger knobs with locking mechanism)
Control And Programming
User interface
Magnetic sensor to call up fixture status and focus fixture
Stand-alone control
Up to 20 scenes with individual fade/ hold times
Control options
DMX, RDM, stand-alone
Configuration, addressing and status
Via RDM
8-bit control
Color and gobo selection
16-bit control
Gobo indexing and rotation, Animation, Focus, Zoom and Intensity
DMX channels
13/14 (Basic / Extended)
DMX compliance
USITT DMX512-A
RDM compliance
ANSI/ESTA E1.20
Optics
Light source
130W White light LED engine LED lifetime: minimum 30,000 hours (to >70% luminous output)* Full Zoom Range: 15° - 45° (Field Angle) *Figure obtained under manufacturer's test conditions
Photometric Data
CRI (Color Rendering Index)
>70 Color Temperature: 7,500 K Fixture Luminous Output: 5,200 lumens Light Engine Luminous Output: 13,000 lumens LED Refresh Rate: 2,400 Hz. * All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient
Construction
Housing
Cast aluminum
Finish
Hard anodized
Front glass
5 mm (0.2 in.) anti-reflection coated tempered glass
Ingress protection
IP66
Impact resistance
IK08
Corrosion resistance
C5 (very high corrosivity / marine, ISO 12944)
Vibration resistance
1.0g, Sinusoidal (IEC 60068-2-6) 0,7g RMS Random (IEC 60068-2-64), 3.0g (ANSI C136-31)
EPA (Effective Projected Area)
0.1 m2
Color options
Traffic Grey RAL 7042, Traffic White RAL 9016, Traffic Black RAL 9017 Service Lid for gobo change or insert of accessory effect modules
Gobos
Suitable material
Borosilicate glass, coatings heatresistant to 450°C (842° F)
Gobo diameter
19.0 mm +0/-0.3 mm (0.74 in. +0/-0.02 in.)
Maximum image diameter
15 mm (0.59 in.)
Glass gobo thickness, minimum
1.1 mm ±0.1 mm (0.045 ±0.004 in.)
Glass gobo thickness, maximum
3.0 mm ±0.3 mm (0.12in. ± 0.012 in.)
Aluminum gobo thickness
0.5 mm ± 0.02 mm (0.020 in. ± 001 in) HT paint
Installation
Mounting
Adjustable yoke
Orientation
Any, except horizontal angles above 70°
Minimum distance to illuminated surfaces
0.5 m (20 in.)
Connections
Power cable entry
IP68 cable gland (accepts 8 mm-12 mm)
Power connection
Terminal for power in separate compartment
Data cable entry
Terminal for power in separate compartment
Data connection
Terminal for data in separate compartment
Electrical
AC power
100-240/277 V nominal, 50/60 Hz Power supply: Auto-ranging electronic switch-mode Surge protection: 4 KV Max earth-leakage current: 0.4 mA Power factor: 0.98 @ 110 V / 0.96 @ 230 V, 0.91 @ 277 V Max current draw: 0.98 @ 110 V / 0.96 @ 230 V, 0.91 @ 277 V Typical current draw: 1.48 A @110 V, 0.71 A @230 V, 0.63 A @ 277 V * Power Consumption Maximum: 180 W Typical: 160 W * Idle: 10 W * Hibernation: 3 W * *Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%. Typical: full output, no effects moving, regulated fan speed. Idle: no output, no effects moving, regulated fan speed. Hibernation: no output, motors de-energized, fans stopped, wake-up procedure to re-use fixture.
Thermal
Cooling
Convection and forced air (temperature regulated)
Maximum surface temperature
60° C (140° F)
Maximum ambient temperature (Ta max.)
45° C (113° F) *
Minimum ambient temperature (Ta min.)
-30° C (-22° F)** *Above this temperature, the fixture regulates output to protect from overheating. **For instant wake-up with no warm-up mode, leave power applied constantly in ambient temperatures below 0° C (32° F)
Environmental
RoHS
Compliant
REACH
Compliant
WEEE
Compliant
Proposition 65
Compliant
FSC
Certified cardboard outer packaging
Efficacy (max output)
32.9 lm/W
LWR*
416 lm/kg (189 lm/lbs.) *LWR = Lumen-to-Weight Ratio
Approvals
Global CB Certification/IECEE
IEC 60598-2-5 (IEC 60598-1)
EU safety
EN 60598-2-5 (EN 60598-1), EN 62471, EN 62493
EU EMC
EN 55015, EN 55032(Class B),EN55035, EN 61000-3-2, EN 61000-3-3, EN 61547
US safety
ANSI/UL 1598
US EMC
CFR 47 Part 15 Class B
Canadian safety
CSA C22.2 No 250.13
Canadian EMC
CAN ICES (B)/ NMB(B)
Australia/NZ
RCM
Thailand
TISI 1955-2551
BIS certification
(Pending)
Korea
KS C 9832, KS C 9835
Included Items
Included Items
4 pcs Insulated ferrules crimp terminal connectors for Power 4 pcs Insulated ferrules crimp terminal connectors for Data 1 pcs desiccant sachet 1 pcs Multi-Language Safety and Installation Manual
