Specifications
Certifications
Approvals
CE Certified, CSA and UL Approved
Dimensions
Length
68.5 cm (27")
Width
18 cm (7")
Height
30 cm (12")
Weight
Product Weight
16.8 kg (37 lbs)
Shipping Weight
30.5 kg (67 lbs) with flight case
Electrical
Operating Voltage
100 - 250 VAC, 50/60 Hz single phase
Power Consumption
715W
Performance
Haze Color
Pure white
Particle Size
0.5 - 0.7 micron
Warm-Up Time
8 minutes (maximum)
Noise Emission
45.4 dB (A) at 1 m (3.3 ft)
Total Running Time
46 hours at 1.38 bar (20 psi) with full tank; 23 hours at 2.76 bar (40 psi) with full tank
Connectivity
DMX Connectors
XLR-5
DMX Channels
3 standard USITT DMX512 channels
RDM Compliant
Yes
Construction
APS
Standard (Automatic Purging System)
Fluid Type
MDG Neutral
Reservoir Capacity
2.5 L (0.66 US gallon)
Fluid & CO2 Consumption
Fluid Consumption (Standard)
55 ml (1.86 oz) per hour at 1.38 bar (20 psi)
Fluid Consumption (High)
110 ml (3.72 oz) per hour at 2.76 bar (40 psi)
CO2 Consumption (Standard)
0.18 kg (0.4 lb) per hour at 1.38 bar (20 psi)
CO2 Consumption (High)
0.36 kg (0.8 lb) per hour at 2.76 bar (40 psi)
