Specifications
Certifications
Approval
CE certified, CSA and UL approved
Dimensions
Length
68.5 cm (27")
Width
18 cm (7")
Height
30 cm (12")
Weight
Product Weight
16.8 kg (37 lb)
Shipping Weight
30.5 kg (67 lb) with flight case
Electrical
Operating Voltage
100 - 250 VAC, 50/60 Hz single phase
Power Consumption
715W
Performance
Haze Color
Pure white
Particle Size
0.5 - 0.7 micron
Warm-Up Time
8 minutes (maximum)
Noise Emission
45.4 dB (A) at 1 m (3.3 ft)
Fluid Consumption
55 ml (1.86 oz) per hour at 1.38 bar (20 psi); 110 ml (3.72 oz) per hour at 2.76 bar (40 psi)
CO2 Consumption
0.18 kg (0.4 lb) per hour at 1.38 bar (20 psi); 0.36 kg (0.8 lb) per hour at 2.76 bar (40 psi)
Reservoir Capacity
2.5 L (0.66 US gallon)
Total Running Time
46 hours at 1.38 bar (20 psi) with full tank; 23 hours at 2.76 bar (40 psi) with full tank
Connectivity
DMX Channels
3 standard USITT DMX512
Connectors
XLR-5
RDM Compliant
Yes
Construction
APS (Automatic Purging System)
Standard
Fluid Type
MDG Neutral
