Specifications
Certifications
Approval
CE certified and ETL field approved
Performance
Fluid Consumption
90 ml (3.04 oz) per minute at full output
Fluid Type
MDG Low Fog Fluid
Reservoir Capacity
2.5 L (0.66 US gallon)
Fog Color
Pure white
Particle Size
0.5 - 4.5 microns
Warm-Up Time
8 minutes (maximum)
CO2 Running Time (Low Pressure)
180 L (48 US gallon) canister (DEWAR) = 70 minutes
CO2 Running Time (High Pressure)
35 kg (77 lb) canister = 13.25 minutes
CO2 Supply
Liquid CO2 Type (Low Pressure)
Refrigerated
Liquid CO2 Type (High Pressure)
Non-refrigerated
Liquid CO2 Consumption (Low Pressure)
3 L (0.79 US gallon) at 15.5 bar (225 psi) per minute
Liquid CO2 Consumption (High Pressure)
2.77 kg (6 lb) at 60.3 bar (875 psi) per minute
Electrical
Operating Voltage
208 VAC or 230 VAC, 50/60 Hz (single phase)
Power Consumption
2,850W
Dimensions
Total Length
1.71 m (67.375")
Operating Length
1.51 m (59.5")
Width
67 cm (26.375")
Height
78 cm (30.625")
Weight
Unit Weight
113 kg (250 lbs)
