Middle Atlantic UPX-RLNK-2000R-2 Nexsys Ups Backup Power System -

Middle Atlantic UPX-RLNK-2000R-2 Nexsys Ups Backup Power System -

SoundPro Item: 202703 | Part Number: UPX-RLNK-2000R-2

$3,519.90
$3,911.00 $3,519.90
Your Price Sold out
MSRP: $3,911.00 | MAP: $3,519.90

Usually ships in 5-7 business days

  • AVR: Yes
  • Plug/Connector Type: NEMA 5-20P
  • Receptacle Type: NEMA 5-20R
  • Receptacle Detail: 8 x NEMA 5-20R
  • Dataline Protection: RJ-45
  • Cord Length: 5.91 ft
  • Transfer Time: 10 ms
  • Load Capacity: 2000 VA/1800 W
  • Input Voltage: 120 V AC
  • Input Voltage Range: 80 V AC - 145 V AC
  • Input Current: 20 A
  • Output Voltage: 110 V AC
  • Output Voltage: 120 V AC
  • Output Voltage: 127 V AC
  • Input Frequency: 60 Hz
  • Waveform Type: Pure Sine Wave
  • Surge Energy Rating: 1000 J
  • Display: LCD
  • Network Management: Dry Contact
Log in or register for YOUR best price

NEXSYS is built on a promise that we've kept for over two decades - more than half the life of the company - that our power products are designed, engineered, and built for AV. It's one thing to say it, it's another thing to prove it. And our NEXSYS Line Interactive UPSs prove it, we promise. They are built with premium components to keep your AV systems running as smoothly as you'd expect.

View full details

Specifications

'General Information
Manufacturer
Legrand Group
Manufacturer Part Number
UPXRLNK2000R2
Brand Name
Middle Atlantic
Product Line
NEXSYS
Product Name
NEXSYS Series - UPS Backup Power with RackLink - 2000VA
Product Type
Line-interactive UPS
Technical Information
AVR
Yes
Plug/Connector Type
NEMA 5-20P
Receptacle Type
NEMA 5-20R
Receptacle Detail
8 x NEMA 5-20R
Dataline Protection
RJ-45
Cord Length
5.91 ft
Transfer Time
10 ms
Power Description
Load Capacity
2000 VA/1800 W
Input Voltage
120 V AC
Input Voltage Range
80 V AC - 145 V AC
Input Current
20 A
Output Voltage
110 V AC
120 V AC
127 V AC
Input Frequency
60 Hz
Waveform Type
Pure Sine Wave
Surge Energy Rating
1000 J
Display & Graphics
Display
LCD
Management
Network Management
Dry Contact
DB-9 RS-232
SmartSlot
Network Card
Interfaces/Ports
Serial Port
Yes
Network (RJ-45)
Yes
USB
Yes
EPO Port
Yes
Battery Information
DC System Voltage
48 V DC
Battery Chemistry
Lead Acid
Backup/Run Time (Full Load)
3 Minute
Backup/Run Time (Half Load)
10 Minute
Typical Battery Recharge Time
8 Hour
Hot Swappable
Yes
Replaceable Battery
Yes
Environmental Conditions
Minimum Operating Temperature
32°F (0°C)
Maximum Operating Temperature
104°F (40°C)
Storage Temperature
5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation
9842.52 ft
Operating Humidity
95%
Sound Emission (A-Weighted)
50 dB(A)
Physical Characteristics
Product Color
Black
Rack Height
2U
Form Factor
Rack/Tower
Miscellaneous
Package Contents
NEXSYS 2000VA Rack/tower UPS 6' (1.8m) IEC Power Cord Network Card
Energy Star
Yes
Environmentally Friendly
Yes
Environmental Certification
REACH
RoHS
Country of Origin
China
Warranty
Limited Warranty
3 Year
Additional Warranty Information
2 Years Battery
