Specifications
Dimensions
Dimensions
1.81" diameter x 7.28"
Electrical
Rated Load Impedance
1 kΩ
Max. SPL for THD 0.5%
134 dB
Max. SPL for THD 0.5% with Preattenuation
140 dB
Max. Output Voltage
0.3 dBu
Supply Voltage (P48, IEC 61938)
48 V ± 4 V
Current Consumption (P48, IEC 61938)
0.8 mA
Audio
Polar Patterns (selectable)
Cardioid, Wide Angle Cardioid, Hypercardioid, Figure-8, Omnidirectional
Frequency Response
20 Hz - 20 kHz
Sensitivity at 1 Khz Into 1 Kohm
8 mV/Pa = −42 dBV ± 1 dB
Signal-to-Noise Ratio CCIR (re. 94 Db SPL)
66 dB
Signal-to-Noise Ratio, A-Weighted (re. 94 Db SPL)
77 dB
Connectivity
Matching Connector
XLR 3 F
Shipping
Weight
14.12 oz
General
Transducer Type
Condenser
Rated Output Impedance
150 Ω
Equivalent Noise Level, CCIR
28 dB
Equivalent Noise Level, A-Weighted
17 dB-A
