Specifications
Dimensions
Diameter
60 mm
Electrical
Maximum SPL for THD 0.5%2)
138 dB
Maximum Output Voltage
13 dBu
Supply Voltage (P48, IEC 61938)
48 V ± 4 V
Current Consumption (P48, IEC 61938)
3 mA
Audio
Polar Pattern
Cardioid
Sensitivity at 1 Khz Into 1 Kohm
23 mV/Pa
Signal-to-noise Ratio, CCIR1) (rel. 94 Db SPL)
76.5 dB
Signal-to-noise Ratio, A-weighted1) (rel. 94 Db SPL)
87 dB
Connectivity
Matching Connector
XLR3F
Shipping
Weight
approx. 450 g
Identifiers
Length
132 mm
General
Transducer Type
Condenser
Rated Output Impedance
50 ohms
Equivalent Noise Level, CCIR1)
17.5 dB
Equivalent Noise Level, A-weighted1)
7 dB-A
Notes
1)according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS, 2) measured as equivalent el. input signal
RF
Frequency Range
20 Hz - 20 kHz
