Specifications
Dimensions
Diameter
64 mm
Height
110 mm (without suspension)
Electrical
Rated Impedance
200 ohms
Rated Load Impedance
10 kohms
Audio
Polar Pattern
Hypercardioid
Max. SPL
150 dB
Sensitivity
1.7 mV/Pa
Sensitivity at 1 Khz Into 1 Kohm
1.7 mV/Pa = –55.4 dB ± 1 dB
Signal-to-noise Ratio, CCIR (re. 94 Db SPL) [3]
62 dB
Signal-to-noise Ratio, A-weighted (re. 94 Db SPL) [4]
76 dB
Shipping
Weight
500g
Identifiers
Length
85 mm
General
Transducer Type
Dynamic
S/N Ratio
76 dB
Equivalent Noise Level, CCIR [1]
32 dB
Equivalent Noise Level, A-weighted [2]
18 dB-A
RF
Frequency Range
20 Hz - 20 kHz
