Specifications
Dimensions
Dimensions
2.36" diameter x 5.2" length
Electrical
Max. SPL for THD 0.5%
138 dB
Max. Output Voltage
13 dBu
Supply Voltage (P48, IEC 61938)
48 V ± 4 V
Current Consumption (P48, IEC 61938)
3 mA
Audio
Polar Pattern
Cardioid
Sensitivity at 1kHz Into 1kΩ
23 mV/Pa = –32.5 dBV ± 1 dB
Signal-to-Noise Ratio, CCIR (re. 94 Db SPL)
76.5 dB
Signal-to-Noise Ratio, A-Weighted (re. 94 Db SPL)
87 dB
Connectivity
Matching Connector
XLR 3 F
Shipping
Weight
approx. 15.87 oz
General
Transducer Type
Condenser
Rated Output Impedance
50 ohms
Equivalent Noise Level, CCIR
17.5 dB
Equivalent Noise Level, A-Weighted
7 dB-A
RF
Frequency Range
20 Hz - 20 kHz
