Specifications
Dimensions
Dimensions
2.21" diameter x 7.87" length
Electrical
Max. Output Voltage
-1 dBu
Supply Voltage (P48, IEC 61938)
P48
Current Consumption (P48, IEC 61938)
3 mA
Audio
Polar Patterns (selectable)
Cardioid, Figure-8, Omnidirectional
Sensitivity at 1kHz Into 1kΩ
10/18/9 mV/Pa (Omni/cardioid/8)
Typical SPL (tube characteristic) for K<0.5%
110/105/111 dB (Omni/cardioid/8)
Typical SPL (tube characteristic) for K <5%
130/125/131 dB (Omni/cardioid/8)
Signal-to-Noise Ratio, CCIR (re. 94 Db SPL)
65/70/64 dB
Signal-to-Noise Ratio, A-Weighted (re. 94 Db SPL)
65/70/64 dB
Connectivity
Matching Connector
XLR 3 F
Shipping
Weight
17.28 oz
General
Transducer Type
Condenser
Rated Output Impedance
50 ohms
Equivalent Noise Level, CCIR
29/24/30 dB (Omni/cardioid/8)
Equivalent Noise Level, A-Weighted
16/11/17 dB-A (Omni/cardioid/8)
RF
Frequency Range
20 Hz - 20 kHz
