Specifications
Dimensions
Dimensions
2.52" diameter x 5.71" length
Electrical
Max. SPL for THD 0.5%
141 dB
Max. SPL for THD <0.5% with Preattenuation -6dB
147 dB
Max. SPL for THD <0.5% with Preattenuation -12dB
153 dB
Max. Output Voltage
10dBu
Supply Voltage (P48, IEC 61938)
48 V ± 4 V
Current Consumption (P48, IEC 61938)
3.2 mA
Audio
Polar Patterns (selectable)
Cardioid, Wide Angle Cardioid, Hypercardioid, Figure-8, Omnidirectional
Sensitivity at 1kHz Into 1kΩ
11 mV/Pa
Signal-to-Noise Ratio, CCIR (re. 94 Db SPL)
72 dB
Signal-to-Noise Ratio, A-Weighted (re. 94 Db SPL)
84 dB
Connectivity
Matching Connector
XLR 3 F
Shipping
Weight
15.7 oz
General
Transducer Type
Condenser
Rated Output Impedance
50 ohms
Equivalent Noise Level, CCIR
22 dB
Equivalent Noise Level, A-Weighted
10 dB-A
RF
Frequency Range
20 Hz - 20 kHz
