Specifications
Weight
Product Weight
3.5 kg (7 lbs 11 oz)
Electrical
Mains Power Supply, Voltage; Frequency
100-240 V~; 50/60 Hz, with standby
Audio
-6 Db Free Field Frequency Response
53 Hz … 22 kHz, ± 6 dB
3 Db Free Field Frequency Response
57 Hz … 21 kHz, ± 3 dB
Pass Band Free Field Frequency Response
59 Hz … 20 kHz, ± 2 dB
Connectivity
Input
XLR, analog electronically balanced
Bass Amplifier, cont.(peak) Output Power*
150 W (130 W)
Treble Amplifier, cont.(peak) Output Power
55 W (70 W)
General
Acoustical
Self-generated noise (with input gain set to 100 dB for 0 dBu): < 20 dB(A) bei 10 cm, Max. SPL in full space at 3% THD at 1m (averaged between 100 Hz and 6 kHz): 102,8 / 108,8 dB SPL
Controller Design
Digital, active
Crossover Frequency, Slopes
1.8 kHz, 48 dB/oct, 8th order
Drivers
100 mm (4"), 25 mm (1"), with integrated black metal grilles
Mounting Points
2 x M6 threaded inserts with 70 mm spacing on back panel
Mechanics
Product dimensions (height x width x depth), mm (inches): 233 x 154 x 194 mm (9 1/8" x 6" x 8 5/8")
