Specifications
Dimensions
Diameter
48 mm
Electrical
Maximum SPL for THD < 0.5%²)
152 dB
Audio
Sensitivity at 1 Khz Into 50 Kohm
4 mV/Pa ≅–48 dBV ± 1 dB
Signal-to-noise Ratio, CCIR¹) (rel. 94 Db SPL)
62 dB
Signal-to-noise Ratio, A-weighted¹) (rel. 94 Db SPL)
73 dB
Compatibility
Shure
Axient Digital, ULX-D, QLX-D, SLX-D Series
Environmental
Operating Temperature Range
0°C - +70°C (32°F - 158°F)
Storage Temperature Range
−20°C - +70°C (−4°F - 158°F)
Humidity Range
max. 90 % at +20 °C
Shipping
Weight
approx. 183 g
Identifiers
Length
80 mm
General
Directional Pattern
Supercardioid
Equivalent Noise Level, CCIR
32 dB
Equivalent Noise Level, A-weighted
21 dB-A
Sony
all models
Mipro
ACT Series
Lectrosonics
all models
Notes
1) according to IEC 60268-1; CCIR-weighting according to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS, 2) measured as equivalent el. input signal
RF
Frequency Range
40 Hz – 20 kHz
