Neutrik NE8FFX6-W etherCON CAT6A Feedthrough Coupler | White

Neutrik NE8FFX6-W etherCON CAT6A Feedthrough Coupler | White

SoundPro Item: 203821 | Part Number: NE8FFX6-W

$38.99
$43.53 $38.99
Your Price Sold out
MSRP: $43.53 | MAP: $38.99

Usually ships in 5-7 business days

  • CAT6A Component Compliance Meets ISO/IEC 11801 And TIA/EIA 568-C.2 Standards
  • IP65 Environmental Sealing Achieved When Mated With Compatible NE8MX6 Connectors
  • Latch Lock Retention System Prevents Accidental Disconnection Under Live Conditions
  • Accommodates Standard RJ45 Plugs For Broad System Compatibility
  • PoE+ Support Per IEEE 802.3at Enables Power-Over-Ethernet Deployments
  • Compact Form Factor Allows Installation In High-Density Panel Configurations
Log in or register for YOUR best price

The Neutrik NE8FFX6-W is a ruggedized etherCON CAT6A feedthrough coupler designed for AV integrators, touring engineers, and system installers who need reliable cable extensions in demanding environments. It accepts standard RJ45 plugs and delivers full CAT6A component compliance per ISO/IEC 11801 and TIA/EIA 568-C.2, making it suitable for high-bandwidth data and PoE+ deployments across permanent installations and live production rigs alike.

This coupler is built for the realities of professional use — whether in a touring snake system, a fixed installation raceways, or a broadcast infrastructure. The compact form factor allows deployment in tight panel configurations, and the robust latch lock mechanism ensures connections stay secured through repeated handling cycles. IP65 protection is achieved when mated with compatible NE8MX6 connectors, qualifying it for outdoor stages, wet environments, and any install where moisture or dust ingress is a concern.

For integrators evaluating alternatives, the NE8FFX6-W stands apart from generic RJ45 keystone couplers through its verified electrical ratings — including dielectric strength exceeding 1.5 kVdc, insulation resistance above 0.5 GΩ, and a rated lifecycle over 1,000 mating cycles — providing the performance assurance that consumer-grade pass-throughs cannot match.

Downloads

View full details

Specifications

Certifications
Protection Class
IP65 (in combination with NE8MX*)
Transmission Performance
CAT6A, Class EA per TIA/EIA 568-C.2 and IEC/ISO/EN
Electrical
Contact Resistance
< 200 mΩ
Dielectric Strength
> 1.5 kVdc
Insulation Resistance
> 0.5 GΩ
Rated Current Per Contact
1.5 A
Power Over Ethernet
PoE+ per IEEE 802.3at
Mechanical
Insertion Force
≤ 50 N
Withdrawal Force
≤ 50 N
Lifetime
> 1000 mating cycles
Wiring
Feedthrough
Locking Device
Latch lock
Gender
Female
Construction
Contact Plating
Au
Shell Material
Rubber (EPDM)
Strain Relief Material
CuZn35Pb2, Tin plated
Environmental
Temperature Range
- 30 °C to + 80 °C
Identifiers
Color
White
