Neutrik NL4MPXX.POLY 4-Pole Chassis Connector
Neutrik NL4MPXX.POLY 4-Pole Chassis Connector
SoundPro Item: 141261 | Part Number: NL4MPXX.POLY
Usually ships in 5-7 business days
- IEC 61984 certified > IEC 62368-1 compliant
- Glass reinforced V-0 materials make it extremely robust and dependable
- Precise keyway for secure mating
- Accurate twist lock latching system
- Metal insert in locking area
- Airtight design - optimized for speaker applications
This connector is fully compliant to the device standard IEC 62368-1, due to its component certification according to IEC 61984.
4 pole chassis connector, black D-size flange, countersunk thru holes, 3/16" flat tabs.
The speakON panel mount connectors are the standard chassis connectors for loudspeaker / amplifier interconnections. They feature a unique metal locking system, making contact only once fully locked. The speakON receptacles are robust, versatile and easy to terminate.
- Product
- Title: NL4MPXX
- Gender: Male
- Electrical
- Contact resistance: ≤ 2 mΩ
- Dielectric strength: 2.8 kVac
- Insulation resistance: >0.1 GΩ (after dampheat)
- Rated current per contact: 25 A rms continuous (audio rating significantly higher, depending on signal)
- Rated voltage: 250 V ac
- Attention: speakON is NOT to be used as an AC mains or power supply connector!
- Mechanical
- Lifetime: > 5000 mating cycles
- Termination: 3/16" flat tabs (e.g. NLFASTON)
- Locking device: Quick Lock
- Chassis shape: D
- Layout: standard hole position, thru holes
- Material
- Contact plating: Ag
- Locking element: Stainless Steel
- Shell: Polyamide (PA 6.6)
- Contacts: Copper Alloy
- Environmental
- Flammability: UL94 V-0
- Temperature range: -30 °C to +80 °C
