Specifications
Frequency Response @-6 dB
45 Hz to 150 Hz
Sensitivity 1W@1m
105 dB SPL Nominal
Peak SPL@1m
136 dB
Crossover Frequency
40-85 Hz, 40-120 Hz, 40- 150 Hz
Nominal Impedance
4 Ω
Recommended Power
850 to 1350 Watts / 4 Ohms
LF Component
1 x 15" 4 Ohms long excursion
Connectors
2 pairs (In/Out) of 7.62 mm pitch screw terminal blocks (+/- poles)
Compatible cables section
Cables from 1.5 mm2 to 3.3 mm2 (AWG 12 to 15) copper section section
Compatible cables outside diameter
Cable with maximum outside diameter of 11 mm
Rigging points
4 x pairs of M10 rigging points (two on each side)
Material
15 mm thick birch plywood body and Magnelis® grille
Finish
Black structural paint (RAL9005 or Custom RAL upon request)
Front Finish
UV & Fire resistant acoustic fabric
Height x Width x Depth
423mm x 531mm x 566mm (16.7" x 20.9" x 22.3")
Weight: Net
26.3 kg (58 lbs)
Operating temperature range
0°C - 40 °C (32° F - 104° F)
Storage temperature range
-20 °C - 60 °C (-4 ° F - 140° F)
IP Rating
IP55
System Operation
Recommended powering solution
NXAMP4x1mk2 Powered TDcontroller: 1 x eLS600 per channel
Optional powering solution
DTD + DTDAMP4x1.3: 1 x eLS600 per channel
NXAMP4x2mk2 Powered TDcontroller: up to 2 x eLS600 per channel
NXAMP4x4mk2 Powered TDcontroller: up to 2 x eLS600 per channel
