• NEXO EPS8 8-Inch Passive Installation Speaker
1 1

NEXO EPS8 8-Inch Passive Installation Speaker | Color: White

NEXO EPS8 8-Inch Passive Installation Speaker | Color: White

SoundPro Item: 132214 | Part Number: EPS8-PW

$1,154.99
$1,441.00 $1,154.99
Your Price Sold out
MSRP: $1,441.00 | MAP: $1,154.99

Usually ships in 5-7 business days

  • Available in black, white, and customizable finishes (black finish pictured only)
  • High power (128 dB peak) point source loudspeaker for fixed installation
  • Lightweight (8.1kg / 17.9lbs) design
  • Robust 15 mm Birch plywood enclosure
  • NEXO’s Asymmetrical Dispersion Constant Directivity horn design (”PS” Horn), rotatable
  • IP55 protection level
  • Comprehensive range of accessories for deploying in a wide variety of fixed installation applications
Log in or register for YOUR best price

Measuring 423mm high x 250mm wide x 227mm deep and weighing 8.1Kg, the ePS8 combines a high excursion 8-inch LF driver with a 1.4-inch voice coil HF driver in a trapezoidal cabinet constructed in a bass-reflex design from 15mm baltic birch plywood. Achieving a peak SPL of 128dB with a frequency range of 80Hz to 20kHz, the ePS8 features a rotatable asymmetric horn, convenient rigging points on the cabinet top, bottom and back, and two pairs of In/Out connectors on pitch screw terminal blocks with an IP cover.

View full details

Specifications

Audio
Frequency Response @-6 Db
80 Hz to 20 kHzSensitivity 1W@1m100 dB SPL NominalPeak SPL@1m128 dBVertical Dispersion+25°/-30°Horizontal Dispersion50° to 100° AsymmetricalCrossover Frequency80 Hz, 120 HzNominal Impedance8ΩRecommended Power350 to 570 Watts / 8 OhmsNumber of ways2 ways passiveLF Component8" 8 Ohms long excursion neodymium driverHF Component1.4" diaphragm 8 Ohms HF driver on an Asymmetrical Dispersion (“PS”) hornConnectors2 pairs (In/Out) of 7.62 mm pitch screw terminal blocks (+/- poles)Compatible cables sectionCables from 1.5 mm2 to 3.3 mm2 (AWG 12 to 15) copper sectionCompatible cables outside diameterCable with maximum outside diameter of 11 mmRigging points3x M6 - 70 mm pitch rigging points (back) + 2x extra M6 and 1x M10 (top/bot)Material15 mm thick birch plywood body and galvanized grilleFinishBlack structural paint (RAL9005 or Custom RAL upon request)Front FinishUV & Fire resistant acoustic fabricHeight x Width x Depth423x250x227mm (16.7x9.8x8.9")Net Weight8.1 kg (17.9 lbs)Operating temperature range0°C - 40 °C (32°F - 104°F)Storage temperature range-20°C - 60°C (-4°F - 140°F)IP RatingIP55System OperationRecommended powering solution:NXAMP4x1mk2 Powered TDcontroller: Up to 3 x ePS8 per channelOptional powering solutionDTDcontroller + DTDAMP4x0.7: Up to 2 x ePS8 per channel DTDcontroller + DTDAMP4x1.3: Up to 2 x ePS8 per channel NXAMP4x2mk2 Powered TDcontroller: Up to 4 x ePS8 per channel NXAMP4x4mk2 Powered TDcontroller: Up to 4 x ePS8 per channel"
