Specifications
Frequency Response @-6 dB
59 Hz to 20 kHz
Sensitivity 1W@1m
100 dB SPL Nominal
Peak SPL@1m
136 dB
Vertical Dispersion
25°
Horizontal Dispersion
80 ° / 120°
Passive Crossover Frequency
1.3 kHz
Nominal Impedance
8 Ohms
Recommended Power
750 Watts
LF Component
1 x 10” 8 Ohms long excursion Neodymium driver with PDDTM
HF Component
1 x 1.4” throat driver on a BEA/FEA optimized HR WavesourceTM
Height x Width x Depth
288mm x 531mm x 355 mm (11.3” x 20.9” x14.0”)
Weight: Net
21 kg (47 lbs)
Connectors
2 x Cable gland with 2 cores cables
Construction
Lightweight Polyurethane Composite
Fittings
4 x Side handles (2 vertical + 2 horizontal) + back grip
Front Finish
Acoustic fabric fitted from grill
Operating temperature range
0°C - 40 °C (32° F - 104° F)
Storage temperature range
-20 °C - 60 °C (-4 ° F - 140° F)
System Operation
Recommended powering solution
NXAMP4x2mk2 Powered TDcontroller: up to 3 x GEO M10 per channel
Optional powering solution
NXAMP4x1 Powered TDcontroller: 1 x GEO M10 per channel
NXAMP4x1 Powered TDcontroller (Bridged): up to 2 x GEOM10 per channel
NXAMP4x4 Powered TDcontroller: up to 4 x GEO M10 per channel
DTD TDcontroller + DTDAMP4x1.3 Power amplifier: up to 2 x GEO M10 per channel
