• NEXO ID14-T 4-Inch Super Compact Passive Speaker
1 1

NEXO ID14-T 4-Inch Super Compact Passive Speaker | Color: White, Coverage: 90x140

NEXO ID14-T 4-Inch Super Compact Passive Speaker | Color: White, Coverage: 90x140

SoundPro Item: 113334 | Part Number: ID14-T90140-PW

$659.99
$823.00 $659.99
Your Price Sold out
MSRP: $823.00 | MAP: $659.99

Usually ships in 5-7 business days

  • Compact, high-powered sound reinforcement speaker
  • 116 dB peak SPL
  • Measures just 130mm W x 130mm H x 120mm D
  • Available in 100° x 100° and 90° x 140° HF dispersion versions
  • Touring version with Magnelis steel grille and Speakon connectivity
  • Black, white and custom RAL colors (only black pictured)
Log in or register for YOUR best price

Thanks to their fully symmetric design, there are there are no left or right versions of the ID14, so all speakers in the inventory can be the same. To ensure maximum versatility, the ID14 can be specified with either 100° x 100° or 90° x 140° HF dispersion.

130mm wide, 130mm high and 120mm front to back, the ID14 is a super-compact full range speaker employing a custom-designed coaxial driver with a 1.3” voice coil for the 4” LF component and a 1.4” diaphragm for the HF motor, delivering smooth, clean sound and impressive power. The Touring version is available in black, white or custom RAL colors and features a Magnelis steel grille and Speakon connectivity.

View full details
  • Frequency Response @-6 dB120 Hz to 20 kHz
  • Sensitivity 1W@1m95 dB
  • Peak SPL@1m116 dB
  • Available Crossover Frequencies120, 150 Hz
  • HF Dispersion (upon ordering) 100° x 100° or 90° x 140°
  • Nominal Impedance16 Ohms
  • Recommended Power110 to 180 Watts / 16 Ohms (requires a 220 to 360 Watts / 8 Ohms amplifier)
  • Number of ways2 ways passive
  • Components1 x Coaxial Neodymium LF 4” long excursion & HF 1.4” diaphragm
  • Connectors2 x NL4, 4 poles connectors (1+/1- Through / 2+/2- ID14)
  • Rigging points1 x M10 on each side for dedicated U bracket + 2 x M6 / 73 mm pitch at the back
  • ConstructionPolyurethane
  • FinishBlack: Raw sandblasted polyurethane / White: Structural paint
  • Front FinishMagnelis® front grill with back mesh
  • Operating temperature range0°C - 40 °C (32°F - 104°F)
  • Storage temperature range-20°C - 60°C (-4°F - 140°F)
  • Height x Width x Depth130x130x120 mm (5.1x5.1x4.7”)
  • Net Weight1.7 kg (3.7 lbs)
  • System Operation
    • Recommended powering solution:DTDcontroller + DTDAMP4x0.7: up to 4 x ID14 per channel
    • Optional powering solution
      • DTDcontroller + DTDAMP4x1.3: up to 4 x ID14 per channel
      • NXAMP4x1mk2 Powered TDcontroller: up to 8 x ID14 per channel
      • NXAMP4x2mk2 Powered TDcontroller: up to 8 x ID14 per channel NXAMP4x4mk2 Powered TDcontroller: up to 8 x ID14 per channel"
