Specifications
Frequency Response @-6 dB
40 Hz to 120 Hz
Sensitivity
105 dB SPL Nominal
Peak SPL@1m
138 dB
Available Crossover Frequencies
40-85 Hz, 40-120 Hz, 40-150 Hz, 63-120 Hz, 63-150 Hz
Nominal Impedance
2Ω
Recommended Power
1300 to 2100 Watts / 2Ω
Components
3 x Neodymium 12" 6 Ohms long excursion
Connectors
Cable gland with 2x core cable
Rigging Points
1 x pair of M6 rigging points to link the IDS312 to a base plate
Construction
15mm baltic birch plywood
Finish
Black structural paint (RAL9005), White structural paint (RAL9016) or Custom RAL
Front Finish
UV & Fire resistant acoustic fabric
Operating temperature range
0°C - 40 °C (32° F - 104° F)
Storage temperature range
-20 °C - 60 °C (-4 ° F - 140° F)
Height x Width x Depth
1160mm x 380mm x 350mm (45.7" x 15.0" x 13.8")
Weight: Net
31 kg (68 lbs)
IP Rating
IP54
System Operation
Recommended powering solution
NXAMP4x1mk2 Powered TDcontroller: 1 x IDS312 per channel
Electronic controllers
NXAMP4x2mk2 Powered TDcontroller: 1 x IDS312 per channel
NXAMP4x4mk2 Powered TDcontroller: 1 x IDS312 per channel
