Specifications
Frequency Response (+6 dB)
40 Hz - 120 Hz
Peak SPL Level (1m)
139 dB Peak
Recommended Amplifiers
850 to 1350 Watts / 4Ω
Crossover Frequency
85 Hz, 120 Hz
Nominal Impedance
4Ω
Components
1x 15" - 4 ohms - Long excursion - Neodymium driver
Connectors
Quick-connect push connector
Rigging Points
1 x Universal accessory fit on each side + 1 x M20 thread for Pole Stand on top
Material
Custom made bent plywood of Baltic birch and poplar
Finish
Black or white structural paint
Front Finish
Steel front grille
Weight
35 kg
Height x Width x Depth
439mm x 550mm x 650 mm (17.3” x 21.7” x 25.6”)
Operating Temperature Range
0°C - 40°C (32°F - 104°F)
Storage Temperature Range
20°C - 60°C (-4°F - 140°F)
System Operation
Recommended Powering Solution
NXAMP4X2MK2: Up to 2 x L15 per channel
Optional Powering Solutions
NXAMP4x1MK2: 1 x L15 per channel
NXAMP4X4MK2: Up to 2 x L15 per channel
