Specifications
DIGITAL AUDIO FORMAT
Digital audio type
AES/EBU
Media type
110 Ohms 3 wires twisted pair with XLR connector
Number of channels
4
Resolution / Sample Rate
24 bits / 44.1 - 96 KHz
Latency
1.4 ms to 2.4 ms
REMOTE CONTROL FORMAT
Network format
Standard TCP/IP
Device addressing
Automatic, based on IP address with Zeroconf
FRONT PANEL FEATURES
Digital audio connectors
2 x XLR-F and 1 x XLR-M
Additional port
2 x RJ45 for remote control
LEDs on digital audio ports
None
LEDs on remote port
Link and Activity
GENERAL SPECIFICATIONS
Power supply
+3.3 Volts, 2 W from NEXO slot
Dimensions (W x D x H)
120 x 160 x 40 mm (NXAMP slot)
Weight
200 g
EMC certification
CE, FCC
Green Status
ROHS and REACH
