Specifications
- Global
- 4 Character LED-display
- 4 Banks x 50 Programs for Drum Kits
- 9 Drum banks for single drum sounds - bass drums, snare drums, toms, hi-hats, cymbals, percussion, bells, tuned percussion, effects
- 8 User Banks x 50 sounds for single drum sounds
- Free OS updates
- Sound Generation
- 6-channel Percussion Modeling Synthesizer
- Tone section - Resonance modeling, Subtractive, Ring Modulation and FM-synthesis
- Noise section - Low pass 12dB/24dB, High Pass 12dB/24dB, High Pass High Cut and Band Pass 6dB/12dB filter. Adjustable resonance and filter envelope response
- Click section - 12 click types, Noise Waveforms, Short Pulses, High Pass Filtered Pulses and Chirps. Adjustable level.
- Effects
- Global Stereo Reverb with 5 reverb modes (Tiled Room, Room, Plate, Stage and Hall) and Color highpass/low pass. Reverb amount can be adjusted per channel.
- Global Delay with Rate (Milliseconds), Feedback and Tap Tempo mode (BPM)
- Drive, Sample Rate Reduction and Ring Modulation Effects per channel
- EQ with Gain and Frequency controls per channel
- Pads and Trigger Input
- 6 integrated rubber pads with adjustable Input Threshold/Sensitivity
- External Trigger input with adjustable Input Threshold/Sensitivity for Kick drum pad or similar
- Adjustable Dynamic Response Curves
- Channel Peak/Activity indicator
- MIDI
- MIDI Note ON/OFF
- MIDI Program Change
- MIDI CC parameter control
- Connections
- 2 Audio Outputs ¼", 6,35 mm (unbalanced)
- Stereo Headphones Output - 1/8”, 3,5 mm
- MIDI in & out - 5 pin DIN connectors
- 1 generic trigger input - ¼”, 6,35 mm
- DC input - 12V, 500mA
- Dimensions11.78" x 1.9" x 11.2"
- Weight4.1 pounds
