Specifications
Certifications
RoHS Compliant
Yes
Dimensions
Dimensions (LxWxH)
11.43×11.61×5.87 cm (4.5×4.57×2.31 in.)
Weight
Weight (with Lithium-Polymer battery)
369 g (13 oz.)
Electrical
Battery Life, Rechargeable Lithium-Polymer
Greater than 9 hours
Charging Power Supply
Micro USB; 6W AC wall adapter
Charge Time for Lithium-Polymer Battery
Under 3 hours
Battery Life, AA Batteries
Approximately 4.5 hours
Audio
Receiver Sensitivity
-100 dBm at 10-5 BER
Audio Dynamic Range
Greater than 90 dB
Audio Frequency Response
150 Hz–7 kHz
Connectivity
Headset Connector
4-pin male XLR
Construction
Material
Polycarbonate substrate with thermoplastic elastomer overmold
Controls
LCD Display
280 × 64 resolution
Environmental
IP Rating
IP-65
Identifiers
Model Number
RP2500
General
RF Frequency (MHz)
902–928 MHz, (915–928 MHz)**
RF Scheme
FHSS with TDMA
Effective Radiated Power
400 mW (+26 dBm)
Radio Certification
FCCID: HSW-CCT900 and IC: 4492A-CCT900
Conferences
2
Simultaneous Listen Paths
True Dual Listen
Volume Knobs
2
Talk Buttons
2
Microphone Type
Auto Detect or Manual Select; Dynamic or Electret
Antenna (2)
2dBi Dipole
Optional Power
3 Standard AA alkaline batteries
Operating Environment
-20° to 50° C (-4° to 122° F); 10% to 90% Humidity, RP Power Supply is 0 to 40° C (32° to 104° F)
Maximum Altitude
2,000 m (6,562 ft.)
RF
Transmission Range
200 m (approx. 650 ft.) under typical conditions; 600 m (approx. 1950 ft.) line of sight (Note: Functional range depends on many variables, including RF signal absorption, reflection, and external interference.)
